TRAINING SOLUTIONS

Comes complete with
™
LiveArc Welding Performance Management System Computer with Intel core i7,
128 GB SSD, fanless cooling, and
See literature TS/1.0
HDMI port for connection to most
The reality-based recruiting, screening, training, and secondary monitors (not included)
re-qualification solution for industrial, manufacturing 21.5 HD LCD touch screen monitor
SmartGun with 15 ft. (4.6 m) cable
and educational markets.
SmartStinger with 12 ft. (3.7 m)
cable
Better and more cost-effective training with faster results.
15 ft. (4.6 m) Dinse-style cable
Benefit from both weld simulation and the real-world experience
Router box
of live arc welding with instant, valuable feedback on welding Calibration tool
technique to quickly help build skills. Two table clamps
C-clamp assembly
Motion-tracking technology measures
Removable arm extension for
the operator’s adherence to preset
out-of-position right- and left-hand
technique parameters. Cameras applications
track the movement of LEDs Extra Bernard® consumables
embedded in the MIG SmartGun Software update for SMAW applications
and SMAW SmartStinger during SmartGun
(left) and
pre-weld simulations and live SmartStinger
welds; the system then delivers (right) shown.
visual feedback on the operator’s
performance via the LiveArc
system’s main display.
Stock Number Input Power Processes Positions Multi-Pass Rated Output Electrode Diameter Dimensions Net Weight
907714001 120 V, 60 Hz GMAW, GMAW-S, 2F–4F, Groove and fillet up to SmartGun: 400 A at SmartGun: Up to H: 77.5 in. (1,969 mm) 527 lb.
Compatible with GMAW-P, FCAW-G 1G–4G 1 in. (25 mm) plate 60% duty cycle (mixed gases) 5/64 in. (2.0 mm) W: 46 in. (1,168 mm) (239 kg)
Miller® power sources SMAW 2F–4F, Limited groove SmartStinger: 250 A at SmartStinger: Up to D: 31 in. (787 mm)
1G–4G applications 60% duty cycle 1/8 in. (3.2 mm)
Educational Resources

Visit MillerWelds.com/education for more information on educational resources.

OpenBook provides FREE interactive Student Safety Packs
online training resources, educational
materials and tracking tools. Visit
OpenBook.MillerWelds.com for details.
All-in-one safety
pack ensures
students are
prepared and
Customize your classroom outfitted with
Implement materials that fit your curriculum and learning comfortable and
objectives, including: fitted personal
— e-Learning modules — Lab builder protection
— Weld lab activities — Customizable certificates equipment (PPE).
— Course builder of completion
— Quiz builder
Miller® and Hobart® pre-defined courses with
certificates of completion
Track individual student progress
All material aligns with AWS standards

Motivate and engage students
Interactive, stimulating learning includes videos and activities
Safety packs consist of black Classic VS auto-darkening 295385 Small
Quick, digestible segments
welding helmet, Classic Cloth jacket, MIG (lined) gloves, 291661 Medium
Mobile friendly TIG/multitask gloves, Classic clear safety glasses, Slag ™ 291662 Large
— Easy to access homework from anywhere shade 5 safety glasses, jobsite tool bag, and more. 291663 X-Large
— Students can check grades and status
Note: Orders must be drop shipped to the school. This offer cannot be 295386 2X-Large
Ideal for high school and post-secondary welding programs combined with any other offer.
