ACCESSORIES

MIGRunner ™ Cart Deltaweld
195445 350/500 2-Wheel Trolley Cart 300971
For AlumaFeed system Running Gear For Maxstar 210/280 and Dynasty
and XMT 350/400 models 301523 210/300 with or without Coolmate
with single-wire feeders. For Deltaweld 1.3. Easy-to-maneuver two-wheel
Small footprint and easily 350/500. cart features single-cylinder rack,
maneuverable, with a Features small chain for cylinder, straps (quick and
dual-cylinder rack low footprint, dual- easy to detach and carry machine),
enough that you do not cylinder rack, cable holders, torch holder, storage
have to lift bottles. chains for area, and filler rod storage area.
Durable, heavy-duty gas cylinders,
ergonomic handles are ergonomic handle design, lockable front casters, two torch
designed for comfort. holders, plus a storage area below.
Small Runner ™ Cart 301615
Continuum Running
Gear/Cylinder Rack For Maxstar 210/280 and
Dynasty 210/300 with or without
301264
For Continuum. Coolmate 1.3. Cart features single-
cylinder rack, foot pedal holder,
Small footprint and
easily maneuverable, two cable/torch holders and two
TIG filler holders.
with cylinder rack low
enough that you do
not have to lift bottles.
Syncrowave 300/400
4-Wheel Cart
301601 Runner ™ Cart 300244
For Syncrowave For Maxstar 400 and
300/400 (machine Dynasty 400/800 with or
only). Cart includes without Coolmate 3.5.
storage space with Cart features single-cylinder
Running Gear Cylinder Rack 300408
latching door, handles, rack, foot pedal holder,
For XMT with single- or dual-wire feeders. Holds two three cable/torch holders
cylinder rack with
large gas cylinders and has gun cable hangers and a
chain, foot control and two TIG filler holders.
consumable drawer in front. A convenient handle allows
holster, and cooler adapter kit. Allows for the addition of a
the cart to be pulled easily through doorways. Power
Coolmate 3 externally powered cooler if desired.
source and single- or dual-wire feeders can be mounted
to cart and secured.
Coolant
™
Coolmate Coolant Systems See literature AY/7.2
Must be ordered in
quantities of four.
One-gallon recyclable
plastic bottle. Miller®
coolants contain
*May vary with torch design and
cable length. Miller®coolant systems a base of ethylene
are backed by the best warranty in glycol and deionized water to protect
the industry — one full year. against freezing to -37 degrees Fahrenheit
(-38°C) or boiling to 227 degrees
Fahrenheit (108°C).
Low-Conductivity Coolant
Coolmate 3.5 Coolmate 4
Coolmate 3 (clear, pre-mixed) 043810
Coolmate 1.3
For TIG and MIG applications. NOT for use
Coolmate 1.3 301616 120 V Coolmate 3.5 300245 120 V in push-pull systems or systems where
For Maxstar 210/280 and Dynasty 210/300. Light industrial, For Maxstar 400 and Dynasty 400/800. Industrial, 3.5-gallon aluminum is in coolant path/circuit.
1.3-gallon cooler designed for water-cooled torches on power cooler designed for water-cooled torches rated up to 600 amps.* Aluminum-Protecting Coolant
sources rated up to 300 amps.* Coolmate 4 042288 120 V (green, pre-mixed) 043809
Coolmate 3 043007 120 V 043008 240 V Best performer in its class — industrial, 4-gallon cooler designed for Primarily used in push-pull systems where
Economical, 3-gallon cooler designed for water-cooled torches water-cooled torches rated up to 600 amps.* aluminum is in coolant path/circuit and
rated up to 500 amps.* high frequency is NOT used.
Model Motor Input Voltage Maximum Current Draw Maximum Cooling Capacity IEC Cooling Capacity Tank Capacity Dimensions Net Weight
Coolmate 1.3 115 V, 50/60 Hz 5.9 A (50 Hz), 4.7 A (60 Hz) 3,400 W (11,600 Btu/hr.) 1,330 W (4,540 Btu/hr.) 1.3 gal. (4.9 L) H: 11.38 in. (289 mm) 46 lb. (21 kg)
3.8 qt./min. (3.6 L/min.) 1.1 qt./min. (1 L/min.) W: 10.38 in. (264 mm)
D: 24.25 in. (616 mm)
Coolmate 3 115 V, 50/60 Hz 5.9 A (50 Hz), 4.7 A (60 Hz) 3,820 W (13,000 Btu/hr.) 1,420 W (4,840 Btu/hr.) 3 gal. (11.4 L) H: 13.25 in. (337 mm) 40 lb. (18 kg)
4.2 qt./min. (4.0 L/min.) 1.1 qt./min. (1 L/min.) W: 12.25 in. (311 mm)
230 V, 50/60 Hz 2.5 A (50 Hz), 3.0 A (60 Hz)
D: 23.25 in. (584 mm)
Coolmate 3.5 115 V, 50/60 Hz 5.9 A (50 Hz), 4.7 A (60 Hz) 4,140 W (14,000 Btu/hr.) 1,660 W (5,660 Btu/hr.) 3.5 gal. (13.2 L) H: 11.75 in. (298 mm) 64 lb. (29 kg)
5.0 qt./min. (4.7 L/min.) 1.1 qt./min. (1 L/min.) W: 15.75 in. (400 mm)
D: 26 in. (660 mm)
Coolmate 4 115 V, 50/60 Hz 5.9 A (50 Hz), 4.7 A (60 Hz) 5,500 W (18,000 Btu/hr.) 1,780 W (6,070 Btu/hr.) 4 gal. (15 L) H: 16.25 in. (413 mm) 38 lb. (17 kg)
5.9 qt./min. (5.6 L/min.) 1.1 qt./min. (1 L/min.) W: 15.25 in. (387 mm)
D: 18.75 in. (476 mm)
123
