ACCESSORIES

Process Selector Control/Polarity Switch Submerged Arc Accessories Torch Accessories
Process Selector Control OBT 600 Torch Body Extensions
Cables
042872 043967 1 inch (25.4 mm)
For CC, CV or CC/CV welding 043969 2 inch (50.8 mm)
power source. Provides an 043973 4 inch (101.6 mm)
easy way to change the 043975 6 inch (152.4 mm)
welding process. Also for
OBT 1200 Torch Body Extension 043981
use with dual wire feeders or any application where
SubArc Control Cables Overall length with extension is 9 inches (228.6 mm).
electrical isolation and/or polarity reversing of weld current
260622030 30 ft. (9.1 m) Actual length of extension is 8.5 inches (215.9 mm).
is required. Both functions can be used at the same time.
260622050 50 ft. (15 m)
OBT Torch Contact Tips
260622060 60 ft. (18.3 m)
OBT 600 OBT 1200 Wire Size
260622080 80 ft. (24.4 m)
Remote Controls 260622100 100 ft. (30.5 m) 192700 192141 1/16 in. (1.6 mm)
192701 199026 5/64 in. (2.0 mm)
Also see Remote Controls in TIG Accessories on pages 260622120 120 ft. (36.6 m)
192702 192142 3/32 in. (2.4 mm)
128 and 129. 260622200 200 ft. (61.0 m)
192703 200771 7/64 in. (2.8 mm)
Cable between SubArc Interface or Motor Control and
PRHC-14 Hand Control 195511 192704 192143 1/8 in. (3.2 mm)
power source.
For all solid-state power sources after 192705 192144 5/32 in. (4.0 mm)
serial number JK674521. Complete 1200-Amp Twin-Wire Torch Contact Tips
current or voltage control brings 264595 3/64 in. (1.2 mm)
120 volts of GFCI power to work area 264596 1/16 in. (1.6 mm)
in a single cord. Housed in a durable 264597 5/64 in. (2.0 mm)
and light alu minum case and includes Flux Hopper Extension Cables 264588 3/32 in. (2.4 mm)
125-foot (38 m) cord with plugs. 260623010 10 ft. (3 m)
260623025 25 ft. (7.6 m)
260623065 65 ft. (19.8 m) Wire Drive Assembly Accessories
Stick Accessory Kits Cable between SubArc Interface or Motor Control and Drive Rolls
flux hopper. 132955 1/16 in. (1.6 mm)
132960 5/64 in. (2.0 mm)
132961 3/32 in. (2.4 mm)
132962 7/64 in. (2.8 mm)
132963 1/8 in. (3.2 mm)
Motor Extension Cables 193700 5/32 in. (4.0 mm)
254232005 5 ft. (1.5 m)
No. 2 Stick Cable Sets
195196 15 ft. (4.6 m), 200 A 254232010 10 ft. (3 m) Single-Wire Straightener 199733
254232025 25 ft. (7.6 m) For OBT 600 and OBT 1200 single-wire
300836 50 ft. (15 m), 200 A
Consists of either 15- or 50-foot electrode cable with 254232065 65 ft. (19.8 m) torches. For 1/16–5/32 inch
Cable between SubArc Interface or Motor Control and (1.6–4.0 mm) wire.
holder and matching length work cable with clamp.
100% duty cycle. drive motor.
Twin-Wire Straightener 301160
For 1200-amp twin-wire torch only.
Single adjustment.
Continuum Motor/Control Cables
263368015 15 ft. (4.6 m)
2/0 Stick Cable Sets
173851 50 ft. (15 m), 350 A 263368025 25 ft. (7.6 m)
263368050 50 ft. (15 m)
043952 100/50 ft. (30/15 m), 300 A
Consists of either 50- or 100-foot electrode cable with holder 263368080 80 ft. (24.4 m)
263368100 100 ft. (30.5 m)
and 50-foot work cable with clamp. 100% duty cycle.
Cable between SubArc Motor Control and
SubArc Remote Pendant.
Manual Single Slide 301137
Provides smooth and accurate movement of the welding
SubArc Parallel Cable
heads. Allows for 7.87 inch (200 mm) travel adjustment
260775015 15 ft. (4.6 m)
with load capacity of 220 pounds (100 kg) at 1.64 feet
(500 mm). Not recommended for tandem.
Weld Cables
195457 2/0 cable with electrode holder, 400 A
SubArc Tandem Cable Wire Reel 108008
195458 2/0 cable with work clamp, 400 A 260878015 15 ft. (4.6 m)
301387 1/0 cable with electrode holder, 250 A Supports 60-pound (27 kg)
coil of wire. Requires Spool
Consists of a stud/Tweco® adapter and 10-foot (3 m)
weld cable with a male Tweco-style plug and either Support Assembly (119438).
an electrode holder or work clamp.
2/0 Weld Cable Extensions
195456 50 ft. (15 m)
Extends weld cables
(195457, 195458 and 301387).
127
