MIG GMAW ALL-IN-ONE

® Industrial
Millermatic 252 See literature DC/12.49
Processes
MIG (GMAW) Flux-cored (FCAW)
Welding Capability Comes complete with
™
15 ft. (4.5 m), 250-amp MDX -250
Max. 1/2 in. (13 mm) MIG gun with AccuLock ™ MDX ™
Max. 3/8 in. (9.5 mm)
consumables
Aluminum welding 10 ft. (3 m) work cable with clamp
uses optional
Mild Steel Aluminum 10 ft. (3 m) industrial power cord
Spoolmatic spool gun.
(and plug on 208/240 V model)
Min. 22 ga. (0.8 mm) Min. 14 ga. (1.9 mm)
Factory-installed gas solenoid
Flow gauge regulator and gas hose
Infinite voltage control with self-calibrating digital meters for argon or AR/CO 2 mix
that permit presetting of voltage and wire feed speed. Factory-installed lowered running
gear/cylinder rack with chain to
Ensures precise parameters and accuracy.
secure gas cylinder
™
EXCLUSIVE! Auto-Gun Detect automatically adjusts voltage, .030/.035 in. reversible dual-groove
wire speed and timers for faster switching between MIG, drive rolls
push-pull and spool guns. Extra contact tips
Integrated digital timers come complete with presettable Most popular accessories
™
Spoolmate 200 Spool Gun (pg 28)
preflow/postflow, burnback, spot and delay (stitch) timers.
Spoolmatic® Spool Gun (pg 29)
Independent timers for MIG and spool gun.
(non-Pro gun only)
™
Superior aluminum MIG welding with direct connection Dual EZ-Change Low Cylinder Rack
of optional Spoolmate 200 and Spoolmatic® spool guns. 300337 (pg 122)
™
Recommended Elevated Gun and Cable Rack
aluminum solution No extra module to buy or install.
300335 (pg 122)
Spoolmatic (page 29). Heavy-duty aluminum two-drive-roll system. Protective Cover 195142 (pg 125)
Uses 4-, 8- or 12-inch (102, 203 or 305 mm) spools. 230-Volt Extension Cord 770644
Visit MillerWelds.com or your distributor
™
Fan-On-Demand cooling system only operates when for other Miller®options and accessories.
needed, reducing power consumption and keeping internal
*With Spoolmatic (30 ft.), additional regulator and dual EZ-Change components cleaner.
low cylinder rack with elevated gun and cable rack.
**While idling.
Amperage Amps Input at Rated Output, 60 Hz Wire Type and Net
Stock Number Range Rated Output 208 V 230 V 240 V 460 V 575 V KVA KW Wire Feed Speed Diameter Capacity Dimensions Weight
907321 208/240 V 30–300 200 A at 24 VDC, 60% duty cycle 57.0 — 50.8 — — 11.4 7.1 50–700 ipm Solid steel H: 30 in. 205 lb.
951960* 208/240 V (1.3–17.8 m/min.) .023–.045 in. (0.6–1.2 mm) (762 mm) (93 kg)
250 A at 26.5 VDC, 40% duty cycle 64.2 — 56.4 — — 12.6 9.4
Stainless W: 19 in.
.023–.045 in. (0.6–1.2 mm) (483 mm)
907322 230/460/575 V 200 A at 24 VDC, 60% duty cycle — 46 — 23 18 9.8 7.5
Flux-cored D: 40 in.
951961* 230/460/575 V 250 A at 26.5 VDC, 40% duty cycle — 2** — 1** 0.8** 0.46** 0.13**
.030–.045 in. (0.8–1.2 mm) (1,016 mm)
