ENGINE-DRIVEN

Light industrial
Fusion 185 See literature ED/2.9
Process
Delivers a smooth, stable arc from either engine power or 120/240-volt utility power, Stick (SMAW)
providing a unique combination of versatility and productivity in a lightweight package. Gasoline engine
Kohler CH440: 13.4 hp at 3,600 rpm
One-cylinder, four-cycle, OHV, air-cooled
Note: Engine is warrantied separately
by engine manufacturer.
Most popular accessories
Work anywhere convenience. Lifting Eye 195353 (pg 124)
PowerShift technology provides weld Running Gear 301246 (pg 124)
capabilities using either the Fusion 185 Twist Lock Adapter Cord 301489
gasoline engine or 120/240-volt utility (pg 124)
Protective Cover 301245 (pg 124)
power. You’ll have the confidence of
Visit MillerWelds.com or your distributor
knowing that you can weld virtually for other Miller®options and accessories.
anywhere with just one machine — outdoors with engine or utility
power and indoors with utility power. The multi-voltage plug (MVP )
™
makes it easy to connect the welder to either 120- or 240-volt power.
Easier to transport. At only 242 pounds, the Fusion 185 is up to
50 pounds lighter than similar machines, so moving it is easier and
faster. Less time is spent waiting, and more work can get done.
Less rework. Inverter technology delivers a smooth, stable stick arc
that’s forgiving of variations in arc length and travel speed, so it’s
easier to produce clean welds that meet specifications — and avoid
the time and expense of rework.
Other features include electric start, 120-volt GFCI and 240-volt
receptacles, 6.25-gallon fuel capacity, auto-idle and engine hour meter.

Stock Number Welding Welding Amperage Amps Input at Rated Output, Single-Phase Auxiliary Net
907781 Input Power Mode Process Range Rated Output at 104°F (40°C) 50/60 Hz, 1-Phase Power at 104°F (40°C) Dimensions Weight
Kohler
H: 24.75 in.
Engine power
185 A at 26.4 V, 20% duty cycle
242 lb.
30–185
DC stick
Gasoline PowerShift 30–100 110 A at 24.4 V, 100% duty cycle 22.7 Continuous: 6,200 watts W: 20.125 in. (110 kg)
Peak: 6,500 watts
—
CC/DC
(629 mm)
90 A at 23.6 V, 40% duty cycle
—
(511 mm)
120 V
D: 31.25 in.
PowerShift 30–185 185 A at 26.4 V, 20% duty cycle 25.0 —
(794 mm)
240 V 110 A at 24.4 V, 100% duty cycle
® Light industrial
Blue Star 185 See literature ED/2.5
Processes
Reliable outdoor mobile power — great for farm, ranch, maintenance and construction. Stick (SMAW) DC TIG (GTAW)
Gasoline engine
Kohler CH440: 13.4 hp at 3,600 rpm
One-cylinder, four-cycle, OHV, air-cooled
Note: Engine is warrantied separately
Compact and mobile. With a small footprint, the Blue Star uses little
by engine manufacturer.
truck space. Optional running gear also makes it one-man mobile.
Most popular accessories
All engine controls are on front panel. Lifting Eye 195353 (pg 124)
Running Gear 301246 (pg 124)
Stick and TIG capable. Protective Cover 301245 (pg 124)
™
Accu-Rated peak auxiliary power is usable for maximum auxiliary Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
power loads such as plasma cutting, Millermatic ® MIG welders and
motor starting.
Other features include electric start, 120-volt GFCI and 240-volt
receptacles, 6.25-gallon fuel capacity, auto-idle and engine hour meter.
Gasoline Stock Number Welding Mode Welding Process Amperage Range Rated Output at 104°F (40°C) Single-Phase Auxiliary Power at 104°F (40°C) Dimensions Net Weight
907664
H: 24.75 in. (629 mm)
296 lb.
60–195
185 A at 25 V, 20% duty cycle
CC/DC
DC stick/TIG
Peak: 6,500 watts
Kohler
Continuous: 6,200 watts
(134 kg)
150 A at 25 V, 100% duty cycle
W: 20.625 in. (524 mm)
D: 31.25 in. (794 mm)
