ENGINE-DRIVEN

™
®
Bobcat/Trailblazer Gas Model Comparison — Which is Right for You?

Bobcat: The most popular engine-driven welder Trailblazer: The best performer in the industry
Cost-effective multiprocess engine-driven welder Unbeatable arc performance
Dependable power and weld output Independent welder and auxiliary power system
Independent welder and auxiliary power system Exclusive technologies — advanced Auto-Speed ™ ,
Easy to maintain Dynamic DIG ™ and optional Excel ™ power
Quietest in its class Most fuel efficient and quietest in its class
Fuel System Bobcat 230 (page 80) Bobcat 265 (page 80) Trailblazer 330 (page 82)
Fuel Type Gasoline Gasoline or LP Gasoline
Delivery Carburetor Carburetor Carburetor (eChoke ™ ) or EFI
(manual choke) (gas: eChoke ™ / LP: manual choke)
Weld
Output DC only, CC/CV DC only, CC/CV DC only, CC/CV
Processes Stick / MIG / FCAW Stick / TIG / MIG / FCAW / Gouge Stick / TIG / MIG / FCAW / Gouge
Amperage Range 20–230 A 20–265 A 20–330 A
Voltage Range 14–25 V 14–28 V 15–40 V
Auxiliary Power
Peak Watts 11,000 watts 11,000 watts 12,000 watts
Continuous Watts 9,500 watts 9,500 watts 10,500 watts
Excel ™ Power (20 A at 120 V, — — 2,400 watts (option)
(60 Hz at all engine speeds)
Sound Levels
Maximum /At Idle 73.1 dB/64 dB 73.1 dB/64 dB 73.5 dB/65 dB
Dimensions
Size (H x W x D) 26.5 x 20.13 x 37.06 in. 26.5 x 20.13 x 37.06 in. 26.5 x 20.13 x 37.06 in.
Weight 376 lb. 382 lb. 400 lb.
Key Features
Display Knob LCD LCD
Maintenance Fuel / Hours/Oil Predictive maintenance Predictive maintenance
Auto-Set ™ — Yes Yes
Battery Charge/Crank Assist — 150 A charge / 300 A crank (option) 150 A charge / 300 A crank (option)
ArcReach® — Yes (option) Yes
Spool Gun Requires WC adapter (page 130) Direct connect Direct connect
Remote Capabilities — Remote start/stop (gas models only) Wireless interface control (option) and 14-pin

™
®
®
Bobcat/Trailblazer/Big Blue Air Pak Comparison — Which is Right for You?
™

Cost-effective Multiprocess Quiet and powerful Heavy-duty,
engine-driven engine-driven multiprocess dual-operator
welder with welder with engine-driven multiprocess
air compressor air compressor welder with engine-driven
and battery charger and battery charger air compressor welder with
air compressor
Bobcat 200 Air Pak (page 79) Trailblazer 330 Air Pak (page 84) Big Blue 600 Air Pak (page 86) Big Blue 800 Duo Air Pak (page 87)
Compressed Air 30 cfm, 175 psi 30 cfm, 160 psi 60 cfm, 100 psi 60 cfm, 100 psi
Battery Charge/Crank Assist 12 and 24 volt 12 and 24 volt — —
Single-phase Peak: 8,000 watts Peak: 12,000 watts Peak: 15,000 watts Peak: 15,000 watts
Auxiliary Power Continuous: 6,500 watts Continuous: 10,500 watts Continuous: 12,000 watts Continuous: 12,000 watts
Three-phase — — Peak: 27,000 watts Peak: 27,000 watts
Continuous: 20,000 watts Continuous: 20,000 watts
Single weld mode: 40–800 amps
Weld Output Range 30–210 amps 20–330 amps 20–600 amps Dual weld mode: 20–400 amps
(CV/DC, CC/DC) (CV/DC, CC/DC) (CV/DC, CC/DC)
(CV/DC, CC/DC)
Fuel Type Gas / Diesel Gas Diesel Diesel
Size 29.78 x 20 x 44.61 in. (gas) 27.02 x 20 x 51.88 46 x 28.5 x 69.5 in. 46 x 28.5 x 69.5 in.
29.75 x 20 x 47.25 in. (diesel)
Weight 514 lb. (gas), 618 lb. (diesel) 587 lb. 2,040 lb. 2,095 lb.
ArcReach® — Yes Yes Yes
Remote Capabilities — Wireless interface control (option) Wireless interface control (option) Wireless interface control (option)
