ENGINE-DRIVEN

Heavy industrial
Options to Maximize Your Trailblazer 330 Performance
®
Processes
Stick (SMAW) MIG (GMAW) 1
Electronic fuel injection (EFI) (gas models) Flux-cored (FCAW) DC TIG (GTAW) 2
1
Adding EFI to your Trailblazer engine-driven welder adds multiple benefits. With EFI, you’ll get faster, Air carbon arc cutting and gouging
(CAC-A) (rated 3/16 in. carbons)
more-reliable starts in any weather — no choke adjustments needed. Add Excel power to your Trailblazer with
1 With wire feeder.
EFI for maximum fuel efficiency. 2 Two-piece TIG torch recommended.
Engines
Gas: Kohler CH730
Wireless interface control (WIC) 23.5 hp at 3,600 rpm
EFI gas: Kohler ECH730
Work hassle-free with full engine-driven welder control in the palm of your hand.
23 hp at 3,600 rpm
With wireless interface control, you can change welding processes, adjust parameters,
EPA Tier 4 Final Diesel: Kubota D902
select and save preset programs, turn the machine on/off, get service reminders and 24.8 hp at 3,600 rpm
more from wherever you are on the jobsite. Extend time between fill ups and maintenance Three-cylinder, industrial, liquid-cooled
intervals while eliminating the need to go back to your machine to make adjustments. Note: Engines are warrantied separately
by engine manufacturer.
Wireless interface control is available as a factory-installed option on select models.
Most popular accessories
SuitCase® Feeders (pg 16/51)
Spoolmate ™ 200 300497 (pg 28)
™
Excel power Spoolmatic® 130831 (pg 29)
ArcReach® Stick/TIG Remote (pg 51)
Excel power delivers a full 2,400 watts (20 A) of 120-volt inverter-based, sine wave Spectrum® 625 X-TREME (pg 96)
™
power at all speeds, including idle. Unlike competitive machines that provide auxiliary Running Gear (pg 124)
power only at 3,600 rpm (max), with Excel power you can operate jobsite tools like Protective Cage with Cable Holders
(pg 124)
grinders at quiet, fuel-saving speeds.
Full KVA Adapter Cord (pg 124)
Refueling time and operating costs are reduced with Excel power, which means more Protective Cover (pg 124)
productivity and profitability. Plus everyone on the jobsite gets a better working Remote Output Panel Kit 951850
environment because noise levels are lowered. Excel power — available only from Miller. Based on only auxiliary-power-only (pg 124)
use for total runtime. HWY-Mid Frame Trailer (pg 125)
Electric Fuel Pump Kit 301741
(gas models only, recommended for
operation at altitudes above 5,000 ft.)
Battery charge/crank assist 25 ft. Battery Charge/Jump Cables
with Plug 300422 (for use with
Reduce downtime with battery charge/crank assist capability. Designed and recommended for mechanics Trailblazer models with battery
or anyone responsible for a fleet of trucks or equipment. By using your Trailblazer to charge dead batteries charge/crank assist)
or jump a stubborn engine, you’ll keep your crew working and the fleet up and running. Provides up to 150 amps Spark Arrestor Kit
of DC current to quickly charge 12- and 24-volt batteries. Jobsite equipment with weak batteries can get up to 300924 Gas
043579 Diesel
300 amps of crank assist.
Wireless Interface Control Screen
Note: Battery charge/jump cables (300422) must be ordered separately.
Protectors 287594 (5 pack)
Screen Protector Kit 301742
Sun Shade 301714
Visit MillerWelds.com or your distributor
for other Miller®options and accessories.

*Electric fuel pump is recommended for gas models operated at altitudes above 5,000 feet.
This feature is standard on EFI Trailblazers and sold as a kit for other gas models (see accessories at right).
Welding Welding Amp/Volt Rated Output at Single-Phase Auxiliary Net
Model Stock Number* Mode Process Ranges 104°F (40°C) Power at 104°F (40°C) Dimensions Weight
Trailblazer 907831 Kohler with GFCI CC/DC Stick/TIG 20–330 A 330 A at 30 V, Peak: H: 26.5 in. (673 mm) 400 lb.
330 907831001 Kohler with Excel power 100% duty cycle 12,000 watts H: 31.2 in. (792 mm) (181 kg)
907832 EFI Kohler with GFCI Continuous: to top of exhaust
907832001 EFI Kohler with Excel power 10,500 watts W: 20.13 in. (511 mm)
Gas 907832002 EFI Kohler with Excel power and WIC Excel power (optional) D: 37.06 in. (941 mm)
907832003 EFI Kohler with Excel power and battery charge/crank assist CV/DC MIG/FCAW 15–40 V 325 A at 30.25 V, 2,400 watts
907832004 EFI Kohler w/Excel power, battery charge/crank assist and WIC 100% duty cycle 20 A at 120 V, 60 Hz
907832005 EFI Kohler with Excel power and polarity reversing auxiliary power at idle
907832006 EFI Kohler with Excel power, polarity reversing and WIC speed and while welding
Trailblazer 907849 Kubota with GFCI CC/DC Stick/TIG 20–330 A 330 A at 31 V, H: 27.02 in. (686 mm) 611 lb.
Diesel 330 Diesel 907849001 Kubota with Excel power CV/DC MIG/FCAW 15–40 V 100% duty cycle H: 32.41 in. (823 mm) (277 kg)
to top of exhaust
907849002 Kubota with Excel power and WIC
330 A at 30.5 V,
907849003 Kubota with Excel power and battery charge/crank assist
W: 20.6 in. (523 mm)
907849004 Kubota with Excel power, polarity reversing and WIC 100% duty cycle D: 45.72 in. (1,161 mm)
83
