BERNARD
Bernard Semi-Automatic Guns Heavy industrial
®
Processes
Miller offers rugged and reliable Bernard welding guns that have been customized to match MIG (GMAW) Flux-cored (FCAW)
Pulsed MIG (GMAW-P)
the performance of many of its industrial wire feeders and power sources.
Duty cycle ratings
100% with CO 2
BTB Air-Cooled MIG Guns See Bernard literature SP-BTB 60% with mixed gases
Suggested feeders
Fully configurable BTB MIG guns help keep your skilled welders comfortable while also
™
Intellx Feeders (pg 11)
increasing their productivity. Continuum Feeder (pg 12)
™
ArcReach® 16 (pg 15)
SuitCase® Series (pg 16)
20 Series and 74 MPa Plus
(pg 18–20)
Suggested power source
Millermatic® 355 (pg 8)
Choose from a variety of necks, handles
Most popular consumables
and trigger styles to optimize welder
ergonomics and weld access, then AccuLock S Consumables
™
standardize with a single line of Diffusers*
consumables to simplify maintenance DS-A1-C Conventional rear-load liner,
B Series handle C Series handle
(regular or small size) and contain costs. See chart below small, thread-on
DS-A2-C Conventional rear-load liner,
for a pre-configured BTB MIG gun.
small, slip-on
Configure your BTB MIG gun by visiting
D-A1-C Conventional rear-load liner,
Tregaskiss.com/ConfigureMyGun
large, thread-on
D-A2-C Conventional rear-load liner,
large, slip-on
Brass Nozzles* (inches)
NS-A1218B 1/2 ID, 1/8 rec., small
Copper Nozzles* (inches)
1 Comes with a Miller®power pin and conventional rear-load liner.
2 Comes with a Miller®power pin and QUICK LOAD®liner. NS-A5818C 5/8 ID, 1/8 rec., small
N-A5818C 5/8 ID, 1/8 rec., large
Stock Number Amperage Cable Length Nozzle Recess Handle Trigger Neck Consumables Wire Size N-A5814C 5/8 ID, 1/4 rec., large
Q3015AE9HMC 1 300 15 ft. (4.6 m) 1/8 in. recess B Series small curved Standard Rotatable med. 45° AccuLock ™ S .052 in. N-A3414C 3/4 ID, 1/4 rec., large
Hytrel® polymer (1.4 mm)
Contact Tips* (inches)
Q3015AE9EMC 1 300 15 ft. (4.6 m) 1/8 in. recess B Series small curved Standard Rotatable med. 45° AccuLock ™ S .045 in. T-A035CH .035
Hytrel® polymer (1.2 mm)
T-A045CH .045
Q4015AE9EMC 1 400 15 ft. (4.6 m) 1/8 in. recess B Series curved Standard Rotatable med. 45° AccuLock ™ S .045 in. T-A052CH .052
Hytrel® polymer (1.2 mm)
T-A062CH 1/16
Q4015VS9EMQ 2 400 15 ft. (4.6 m) 1/8 in. recess C Series straight Standard Fixed med. 60° AccuLock ™ S .045 in. *Small diffusers are compatible with small
Hytrel® polymer (1.2 mm)
nozzles; large diffusers are compatible
with large nozzles. The contact tips listed
above are compatible with both small and
AccuLock S Consumables large diffusers.
™
Visit Tregaskiss.com or your distributor
See Bernard literature SP-ALS for additional Bernardconsumable options.
Accu L ck TM
Increase tip life, reduce replacement
frequency
Contact tips are 60% buried within the
diffuser for less exposure to the heat of
the weld
Mating tapers on both tip-to-diffuser Now available with select Miller
and diffuser-to-neck connection provide packages. Scan the QR code or visit
good electrical conductivity Tregaskiss.com/acculocks-systems
Shielding gas cools contact tip tail to find out more.
