ALUMINUM MIG GUNS

Spoolmatic Spool Guns Industrial
®
Use with CC/CV, DC power sources.
Processes
Portable, aluminum wire feeder for industrial applications.
MIG (GMAW) with aluminum and
other soft alloy wires
Spoolmatic See literature M/1.73 MIG (GMAW) with solid wires
Pulsed MIG (GMAW-P) with
Integrated spool canister rotates 180 degrees for operator flexibility
pulsing power source
and comfort.
Suggested power sources
Available in 15- or 30-foot cable lengths, providing flexibility to be
For Spoolmatic (non-Pro model only)
used in the shop and in the field. Millermatic® 252 (pg 6)
Spoolmatic Millermatic® 255 (pg 7)
Two-stage trigger with built-in gas valve allows for gas preflow and
eliminates the need to purge long gas lines. Millermatic® 355 (pg 8)
Multimatic® 235 (pg 43)
Wire feed speed adjustment on the gun handle and reversible drive Multimatic® 255 (pg 44)
rolls save time and money. For both Spoolmatic models
™
Quick-change, single-turn contact tip provides excellent performance Bobcat ™ 200 Air Pak (pg 79)
PORTABLE! and is easy to replace. Bobcat ™ 265 (pg 80)
Trailblazer® Series (pg 82–84)
These power sources require
Spoolmatic Pro (additional features) See literature M/1.76 WC-24 control (137549)
AlumaPower ™ MPa (pg 9)
Wire tension settings. 4000- or 5000-specific tension settings ensure
XMT® Series (pg 46–50)
the very best wire feeding performance and arc consistency.
Big Blue® Series (not compatible with
More durable motor and drive design improves feedability and arc Big Blue 450 Duo CST) (pg 84–87)
consistency while helping reduce downtime and maintenance costs. Most popular accessories
Spoolmatic Pro Easy access to drive assembly and removable toolless head tube WC-115A 137546 (pg 130)
reduce service time by allowing a means of changing drive rolls and head WC-115A with contactor
137546011 (pg 130)
tube, or performing routine maintenance, without disassembly of gun.
WC-24 137549 (pg 130)
Easy-to-rotate, self-seating head tube allows for better access into Visit MillerWelds.com or your distributor
tight spots, preventing leaks and providing excellent current transfer. for other Miller®options and accessories.
™
Head tubes are common with the XR-Aluma-Pro ™ and XR -Pistol-Pro guns.
Head tube options in several different lengths and bend configurations
are available for when a standard head tube doesn’t fit the application.
*Spoolmatic Pro requires gun wire kit (230708) to run 1/16 in. (1.6 mm) wire.
Wire Type and Maximum Spool Gun Only
Model/Stock Number Welding Current Rating Wire Feed Speed Diameter Capacity Size Capacity Dimensions Net Weight
Spoolmatic 200 A at 100% duty cycle 70–875 ipm (1.8–22.2 m/min.) Aluminum* 4 in. (102 mm) H: 10.25 in. (260 mm) 2.9 lb.
195156 15 ft. (4.6 m) cable Wire speed dependent on control box .030–1/16 in. (0.8–1.6 mm) W: 2.5 in. (64 mm) (1.3 kg)
130831 30 ft. (9 m) cable or power source used Solid wire L: 15.125 in. (384 mm)
Spoolmatic Pro 200 A at 100% duty cycle 70–900 ipm (1.8–23 m/min.) .030–.045 in. (0.8–1.1 mm) H: 10.75 in. (273 mm) 3.0 lb.
301147 15 ft. (4.6 m) cable Wire speed dependent on control box W: 2.5 in. (64 mm) (1.4 kg)
301148 30 ft. (9 m) cable or power source used L: 15.375 in. (390 mm)

®
Hobart aluminum filler metals — wire and cut lengths —
have been designed to provide the best performance for the
best welds. These products are backed by the deep industry
knowledge of Hobart welding specialists who can help
customers find the right aluminum filler metal solution.
Every time. No matter how challenging the application.
Visit HobartBrothers.com or your local distributor to learn more.

Questions? Hobart is here to help.

29
