A FLE24 Cat P 69 TIG Torches.qxp_TIG 1/11/24 5:41 PM Page 1

WATER-COOLED TIG TORCHES

™
Weldcraft W-280 Super Cool ™ See literature AY/30.0 Applications
Aerospace Aluminum fabrication
Automotive Manufacturing
Formerly known as WP-280 Exotic material fabrication
Precision metal fabrication
Pressure vessel fabrication
Reliable water-cooled torch designed for demanding, Shipbuilding Tool and die
Tube and pipe Vocational
high-amperage applications.
Most popular consumables
Insulator (non-gas lens and gas lens)
Super Cool technology provides additional surface area to (required) 598882
increase cooling efficiency and capacity. Collets (non-gas lens and gas lens)
13N21 .040 in. (1.0 mm)
Reduce downtime due to overheating through consistent
13N22 1/16 in. (1.6 mm)
water-cooled performance.
13N23 3/32 in. (2.4 mm)
Reduce leakage of gas and water through secure mechanical 13N24 1/8 in. (3.2 mm)
fittings and connections. Collet Bodies
13N26 .040 in. (1.0 mm)
13N27 1/16 in. (1.6 mm)
13N28 3/32 in. (2.4 mm)
13N29 1/8 in. (3.2 mm)
Braided Rubber Braided Rubber with 50 mm Dinse
Model 12.5 ft. (3.8 m) 25 ft. (7.6 m) 25 ft. (7.6 m) Type Rated Output Electrode Range Gas Lens
45V42 .040 in. (1.0 mm)
W-280 Super Cool 301251012 301251025 301251001 Water-cooled DC: 280 A at 100% duty cycle .020–1/8 in. 45V43 1/16 in. (1.6 mm)
AC: 195 A at 100% duty cycle (0.5–3.2 mm)
45V44 3/32 in. (2.4 mm)
45V45 1/8 in. (3.2 mm)
Weldcraft W-375 Super Cool ™ See literature AY/32.5 Alumina Nozzles
™
13N08
#4, 1/4 in.
13N09 #5, 5/16 in.
13N10 #6, 3/8 in.
Reliable water-cooled torch designed for demanding, 13N11 #7, 7/16 in.
13N12 #8, 1/2 in.
high-amperage applications. 13N13 #10, 5/8 in.
53N58 #4, 1/4 in. (gas lens)
Super Cool technology provides additional surface area to 53N59 #5, 5/16 in. (gas lens)
53N60 #6, 3/8 in. (gas lens)
increase cooling efficiency and capacity.
53N61 #7, 7/16 in. (gas lens)
Reduce downtime due to overheating through consistent 53N61S #8, 1/2 in. (gas lens)
water-cooled performance. Back Caps
41V33 Short
Reduce leakage of gas and water through secure mechanical 41V35 Medium
fittings and connections. 41V24 Long
Most popular accessories
Cable Covers
WC0183 11.75 ft. (3.6 m)
Braided Rubber Braided Rubber with 50 mm Dinse
Model 12.5 ft. (3.8 m) 25 ft. (7.6 m) 25 ft. (7.6 m) Type Rated Output Electrode Range WC0182 24.25 ft. (7.4 m)
W-375 Super Cool 301253012 301253025 301253001 Water-cooled DC: 375 A at 100% duty cycle .020–1/8 in. Visit MillerWelds.com or your distributor
AC: 265 A at 100% duty cycle (0.5–3.2 mm) for other Miller®options and accessories.
™ Applications
Weldcraft W-350 Series See literature AY/32.0 Fabrication Manufacturing
Maintenance and repair
Formerly known as WP-18 Series Shipbuilding Tube and pipe
Most popular consumables
Rugged water-cooled torches engineered
Collets
for high-amperage and continuous 10N24 3/32 in. (2.4 mm)
hand-held welding. 10N25 1/8 in. (3.2 mm)
54N20 5/32 in. (4.0 mm)
Reduce downtime and costs by minimizing Collet Bodies
10N32 3/32 in. (2.4 mm)
overheating with the unique cooling design
W-350 W-350 Valve 10N28 1/8 in. (3.2 mm)
(WP-18) (WP-18V) engineered for operator comfort. 406488 5/32 in. (4.0 mm)
Reduce discomfort and fatigue using the Alumina Nozzles
comfortable handle design. 10N48 #6, 3/8 in.
10N47 #7, 7/16 in.
Superior gas flow control (W-350 Valve) 10N46 #8, 1/2 in.
offered through the built-in fingertip gas control. 10N45 #10, 5/8 in.
10N44 #12, 3/4 in.

Rubber Vinyl
Model 12.5 ft. (3.8 m) 25 ft. (7.6 m) 12.5 ft. (3.8 m) 25 ft. (7.6 m) Type Rated Output Electrode Range
W-350 WP-18-12-R WP-18-25-R WP-18-12 WP-18-25 Water-cooled DC: 350 A at 100% duty cycle .020–5/32 in. (0.5–4.0 mm)
AC: 250 A at 100% duty cycle
W-350 Valve — WP-18V-25-R — WP-18V-25
69
