ENGINE-DRIVEN

® Heavy industrial
Big Blue 800 Series See literature ED/14.0
Processes
The most powerful lineup of diesel engine-driven welders in the industry. Robust output for Stick (SMAW) MIG (GMAW) 1
1
Flux-cored (FCAW) DC TIG (GTAW)
welding and auxiliary power; ideal for dual-operator applications on labor-intensive or RMD® Pulsed MIG (GMAW-P) 2
2
limited-space jobsites. Submerged arc (SAW)
Air carbon arc cutting and gouging
(CAC-A) (rated 1/2 in. carbons)
Stud (1/2 in.)
Make parameter changes 1 With wire feeder.
2 With ArcReach Smart Feeder.
at the weld joint, reducing
walks to the machine. Diesel engine
EPA Tier 4 Final
Increase arc-on time,
Deutz TD2.9 L4: 65.7 hp at 1,800 rpm
improve your bottom line
Turbo-charged, four-cylinder, industrial,
and improve jobsite safety.
liquid-cooled
Standard on all models. Note: Engines are warrantied separately
by engine manufacturer.
Most popular accessories
SuitCase® Feeders (pg 16/51)
Work hassle-free with full ArcReach ® Smart Feeder (pg 16/51)
engine-driven welder control ArcReach ® Stick/TIG Remote (pg 51)
in the palm of your hand. ArcReach ® Heater (pg 51/94)
Factory-installed option on Dynasty 210® Series (pg 61)
Full KVA Adapter Cord 300517
select models.
Big Blue 800 Big Blue 800 Note: WIC-equipped Big Blue 800 Series (pg 124)
Duo Pro Duo Air Pak Full KVA Plug Kit (pg 124)
Wireless interface machines include two remotes so both
control (WIC) optional operators have full control of their processes 119172 Single-phase
on select models. and parameters. 254140 Three-phase
Protective Cover 301113 (pg 124)
Remote Output Panel Kit 951850
—
One dependable engine
One dependable engine
Multi-arc welding. One dependable engine — Provides independent control of the (pg 124)
two independent arcs with up to 400 amps each. fluidity of the weld puddle (arc control) HWY-225 Trailer 301338 (pg 125)
Or plug in additional inverters for a true multioperator and the drive of the arc (DIG range). Desiccant Air Dry System
work platform! Example: Two additional XMT ® machines This delivers a tailorable and user-friendly arc to match (Air Pak model only)
equals four operators, up to 200 amps each. Premium the application, material, fit-up and welder technique. 195117 Side mount
195117001 Rear mount
quality arcs allow operators to work independently with Industrial USB port. Upload the latest software and Eliminates moisture in the air stream
no arc interaction. Multioperator welding has never download machine log files to retrieve information such and prevents air line freeze-ups in
been easier or more versatile. as diagnostics and machine statistics. cold climates
Increased efficiency. More arcs and better fuel economy Cold Weather Kit 301482
20,000 watts of auxiliary power. Plug in Miller®
equal increased profits for your business. Estimated inverter-based power sources for additional welding arcs. Spark Arrestor Kit 195012
Wireless Interface Control Screen
savings are up to 34 percent with a dual-operator unit
Other features include digital meters with SunVision, ™ Protectors 287594 (5 pack)
versus two single-operator units. Visit MillerWelds.com or your distributor
auto matic idle, 120-volt block heater and vandalism
Simple paralleling switch makes switching from a lockout kit (protects control panel and receptacles). for other Miller®options and accessories.
single operator to dual operators a breeze. Weld up to
Ingersoll Rand ultra-reliable industrial rotary screw
400 amps per side when set up in dual-operator mode,
™
compressor (Air Pak model only). 30,000-hour life
or up to 800 amps in single-operator mode.
expectancy. Independent on/off control for applications
Electronic engine display not requiring compressed air — allows greater fuel savings
simultaneously displays fuel level, and longer compressor service intervals.
engine hours, coolant temperature, oil
pressure, battery volts and engine rpm.
Also tracks oil change intervals and
displays engine diagnostics for easier servicing. Air Pak
model adds air pressure and compressor hours displays.
*Big Blue 800 Duo Air Pak has welder truck specific models available — visit MillerWelds.com or your distributor for more information.
Model/Stock Number* Welding Amp/Volt Rated Output at 100% Duty Auxiliary Power
Big Blue 800 Duo Pro Mode/Process Output Mode Ranges Cycle at 104°F (40°C) at 104°F (40°C) Dimensions Net Weight
907751 Deutz CC/DC Separate (dual outputs) 20–400 A 400 A at 36 V (each side) Three-phase H: 46 in. (1,168 mm) Duo Pro:
907751001 Deutz with WIC (Stick/TIG) Peak: 27,000 watts H: 53.5 in. (1,359 mm) 1,869 lb. (848 kg)
Paralleled (combined) 40–800 A 700 A at 44 V, 800 A at 38 V
Big Blue 800 Duo Air Pak Continuous: 20,000 watts to top of exhaust Duo Air Pak:
Diesel 907752 Deutz CV/DC Separate (dual outputs) 15–50 V 400 A at 34 V (each side) Single-phase W: 28.5 in. (724 mm) 2,095 lb. (968 kg)
907752003 Deutz with WIC
D: 69.5 in. (1,765 mm)
Peak: 15,000 watts
(MIG/FCAW)
Paralleled (combined) 15–50 V 750 A at 40 V, 800 A at 38 V Continuous: 12,000 watts
Air Compressor (Air Pak model only) Features Free Air Delivery Working Pressure Constant Duty Cycle Oil Capacity
3
Ingersoll Rand CE55 G1 Rotary screw with electric clutch for on/off, oil change Idle: 40 cfm (1.13 m /min.) 100 psig (7 bar) 100% 4 qt. (3.79 L)
3
intervals of 500 hours, life expectancy of 30,000 hours Weld: 60 cfm (1.70 m /min.)
