ENGINE-DRIVEN

Trailblazer 330 Air Pak ™ See literature ED/4.79 Heavy industrial
®
Processes
Powerful all-in-one tool designed for repair and construction with multiprocess weld quality, DC stick (SMAW) MIG (GMAW) 1
2
1
Flux-cored (FCAW) DC TIG (GTAW)
auxiliary power, air compressor and battery charge/crank assist. Air carbon arc cutting and gouging
(CAC-A) (rated 3/16 in. carbons,
Trailblazer 330 benefits and technology. Equipped with all the standard capable 1/4 in. carbons)
technology of the Trailblazer 330 (gas) models with the addition of an 1 With wire feeder.
air compressor. 2 Two-piece TIG torch recommended.
Strongest combined auxiliary/compressor power. Delivers an industry- Gasoline engine
Kohler CH749: 27 hp at 3,600 rpm
leading 12,000 watts of peak auxiliary power independent of weld settings.
V-twin-cylinder, four-cycle, overhead
Rotary screw air compressor. Delivers up to 30 cfm and 160 psi with valve, industrial, air-cooled
no storage tank and runs many tools at idle speed. Provides 100 percent Note: Engine is warrantied separately
deliverable air, rated at an industry-high 104 degrees Fahrenheit. Front by engine manufacturer.
panel adjustment and automatic overpressure shutdown with indication. Most popular accessories
30,000-hour life expectancy and warrantied for three years by Miller. SuitCase® Feeders (pg 16/51)
Spoolmate ™ 200 300497 (pg 28)
Battery charge/crank assist. Provides up to 150 amps of DC current to
Spoolmatic® 130831 (pg 29)
quickly charge 12- and 24-volt batteries. Jobsite equipment with weak ArcReach® Stick/TIG Remote (pg 51)
batteries can get up to 300 amps of crank assist. Spectrum® 625 X-TREME (pg 96)
™
Note: Battery charge/jump cables (300422) must be ordered separately. Protective Cover (pg 124)
25 ft. Battery Charge/Jump Cables
Wireless interface control (WIC) on select models. See page 83 for
with Plug 300422
more information.
Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
Stock Number Welding Welding Amp/Volt Rated Weld Output Single-Phase Auxiliary Net
907836 Kohler with GFCI Mode Process Ranges at 104°F (40°C) Power at 104°F (40°C) Dimensions Weight
907836001 Kohler with GFCI and WIC CC/DC Stick/TIG 20–330 A 314 A at 32.5 V, 100% duty cycle Peak: 12,000 watts H: 27.02 in. (686 mm) 587 lb.
Gasoline 907836003 Kohler with GFCI, cooler/separator CV/DC MIG/FCAW 15–40 V 330 A at 30.5 V, 100% duty cycle Continuous: 10,500 watts H: 31 in. (787 mm) to top of exhaust (266 kg)
907836002 Kohler with GFCI and cooler/separator
W: 20.46 in. (520 mm)
and WIC
D: 51.88 in. (1,318 mm)
Rotocomp Features Free Air Delivery Working Pressure Duty Cycle Oil Capacity
Air Compressor
3
Rotary screw with electric clutch for on/off, oil change intervals of 500 hours 30 cfm (0.85 m /min.) at 3,600 rpm 80–160 psig 100% 1.75 qt. (1.7 L)
® Heavy industrial
Big Blue 400 Pro See literature ED/5.7
Processes
The professional welder’s choice — designed with the professional in mind, the Big Blue 400 Pro Stick (SMAW) MIG (GMAW) 1
1
Flux-cored (FCAW) DC TIG (GTAW)
is the best for ease of use, reliability and fuel economy. RMD ® Pulsed MIG (GMAW-P) 2
2
Air carbon arc cutting and gouging
Make parameter changes at the weld joint,
(CAC-A) (rated 3/16 in. carbons)
reducing walks to the machine. Increase
1 With wire feeder.
arc-on time, improve your bottom line and 2 ArcReach models only with ArcReach
improve jobsite safety. Factory-installed Smart Feeder.
option on select models. Diesel engines
EPA Tier 4 Final choices
Work hassle-free with full engine-driven
Caterpillar C1.5T: 24.7 hp at 1,800 rpm
welder control in the palm of your hand.
Turbo-charged, three-cylinder, industrial,
Factory-installed option on select models. liquid-cooled
Kubota V1505: 20.2 hp at 1,800 rpm
Provides independent control of the fluidity of the weld
Four-cylinder, industrial, liquid-cooled
puddle (arc control) and the drive of the arc (DIG range). Mitsubishi S4L2: 24.7 hp at 1,800 rpm
This delivers a tailorable and user-friendly arc to match Four-cylinder, industrial, liquid-cooled
the application, material, fit-up and welder technique. Note: Engines are warrantied separately
by engine manufacturer.
Industrial USB port. Upload the latest software and download machine
Most popular accessories
Wireless interface log files to retrieve information such as diagnostics and machine statistics.
control (WIC) optional SuitCase® Feeders (pg 16/51)
on select models. Quiet operation. Only 71.6 decibels (96 Lwa) under full load. Improves ArcReach® Smart Feeder (pg 16/51) 3
jobsite communication and safety. Protective Cover 195301 (pg 124)
3 For ArcReach models only.
™
Other features include digital meters with SunVision, automatic idle,
Visit MillerWelds.com or your distributor
™
adjustable Hot Start, output contactor control and 120-volt block heater. for other Miller®options and accessories.
Stock Number Welding Welding Amp/Volt Single-Phase Auxiliary
907774 CAT Mode Process Ranges Rated Output at 104°F (40°C) Power at 104°F (40°C) Dimensions Net Weight
907774001 CAT with ArcReach
CAT: 1,010 lb. (458 kg)
20–400 A
300 A at 32 V, 100% duty cycle
CC/DC
Stick/TIG
H: 32 in. (813 mm)
Peak: 12,000 watts
Diesel 907732 Kubota 350 A at 27 V, 100% duty cycle Continuous: 10,000 watts H: 37 in. (876 mm) to Kubota: 950 lb. (431 kg)
907732001 Kubota with ArcReach
Mitsubishi: 993 lb. (450 kg)
400 A at 24 V, 100% duty cycle
top of exhaust
907732013 Kubota with ArcReach and WIC CV/DC MIG/FCAW 14–40 V W: 26.25 in. (667 mm)
907733 Mitsubishi D: 56 in. (1,422 mm)
907733001 Mitsubishi with ArcReach
84
