ENGINE-DRIVEN

Big Blue 500 Pro and 600 Series Heavy industrial
®
Processes
See literature ED/11.0 (500) and ED/11.5 (600) Stick (SMAW) MIG (GMAW) 1
1
Flux-cored (FCAW) DC TIG (GTAW)
Clean, quiet, multiprocess machines designed to give welders the output they need for RMD® Pulsed MIG (GMAW-P) 2
2
heavy-duty applications in fabrication and on construction sites. Submerged arc (SAW)
Air carbon arc cutting and gouging
(CAC-A) (500: rated 5/16 in. carbons;
600: rated 3/8 in. carbons)
1 With wire feeder.
2 ArcReach models only with ArcReach
Smart Feeder.
Make parameter changes
Diesel engines
at the weld joint, reducing
EPA Tier 4 Final choices
walks to the machine.
500 and 600 Pro: Kubota V2403
Increase arc-on time, 48.9 hp at 1,800 rpm
improve your bottom line Turbo-charged, four-cylinder, industrial,
and improve jobsite safety. liquid-cooled
Standard on all Deluxe and 600 Air Pak: Deutz TD2.9 L4
65.7 hp at 1,800 rpm
Air Pak models.
™
Turbo-charged, four-cylinder, industrial,
liquid-cooled
Note: Engines are warrantied separately
by engine manufacturer.
Work hassle-free with full
Most popular accessories
engine-driven welder control
SuitCase® Feeders (pg 16/51)
in the palm of your hand.
Big Blue 500 Big Blue 600 ArcReach® Smart Feeder (pg 16/51) 3
and 600 Pro Air Pak Factory-installed option on ArcReach® Stick/TIG Remote (pg 51) 3
select models. ArcReach® Heater (pg 51/94) 3
Wireless interface
Dynasty 210® Series (pg 61)
control (WIC) optional
on select models. Full KVA Adapter Cord (pg 124)
Full KVA Plug Kit (pg 124)
Protective Cover (pg 124)
301495 Kubota
Electronic engine display 20,000 watts of auxiliary power. Plug in Miller®
301113 Deutz
simultaneously displays fuel level, inverter-based power sources for additional welding arcs.
Remote Output Panel Kit 951850
engine hours, coolant temperature, Other features include digital meters with SunVision, ™ (pg 124)
oil pressure, battery volts, and engine adjustable Hot Start, output contactor control, HWY-225 Trailer 301338 (pg 125)
™
rpm. Also tracks oil change intervals automatic idle, thermal overload protection and Desiccant Air Dry System
and displays engine diagnostics for easier servicing. 120-volt block heater. (for Air Pak model only)
195117 Side mount
Provides independent control of the Deluxe and Air Pak models add ArcReach technology, 195117001 Rear mount
™
fluidity of the weld puddle (arc control) polarity reversing switch and vandalism lockout kit Eliminates moisture in the air stream
and the drive of the arc (DIG range). (protects control panel and receptacles). and prevents air line freeze-ups in
This delivers a tailorable and user-friendly arc to match cold climates
Ingersoll Rand ultra-reliable industrial rotary screw Cold Weather Kit 301482
the application, material, fit-up and welder technique.
compressor (Air Pak model only). 30,000-hour life Spark Arrestor Kit 195012
™
Industrial USB port. Quickly upload the latest software expectancy. Independent on/off control for applications Wireless Interface Control Screen
and download machine log files to retrieve in-depth not requiring compressed air — allows greater fuel Protectors 287594 (5 pack)
information such as diagnostics and machine statistics. savings and longer compressor service intervals. 3 For ArcReach models only.
Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
*Big Blue 600 Series has welder truck specific models available — visit MillerWelds.com or your distributor for more information.
Welding Amp/Volt Auxiliary Power at
Model/Stock Number Mode/Process Ranges Rated Output at 104°F (40°C) 104°F (40°C) Dimensions Net Weight
Big Blue 500 Pro CC/DC 20–500 A 400 A at 36 V, 100% duty cycle Three-phase H: 46 in. (1,168 mm) 1,750 lb. (794 kg)
907736 Kubota (Stick/TIG) 450 A at 38 V, 100% duty cycle Peak: 27,000 watts H: 53.5 in. (1,359 mm)
907736001 Kubota Deluxe model 500 A at 40 V, 100% duty cycle Continuous: 20,000 watts to top of exhaust
907736008 Kubota Deluxe model with WIC CV/DC 15–50 V Single-phase W: 28.5 in. (724 mm)
(MIG/FCAW) Peak: 15,000 watts D: 69.5 in. (1,765 mm)
Continuous: 12,000 watts
Diesel Big Blue 600 Pro* CC/DC 20–600 A 600 Pro: Three-phase H: 46 in. (1,168 mm) 600 Pro:
500 A at 40 V, 100% duty cycle
907737 Kubota
H: 53.5 in. (1,359 mm)
(Stick/TIG)
Peak: 27,000 watts
1,750 lb. (794 kg)
550 A at 42 V, 60% duty cycle
907737001 Kubota Deluxe model
to top of exhaust
Continuous: 20,000 watts
907737003 Kubota Deluxe model with WIC 600 A at 42 V, 40% duty cycle Single-phase W: 28.5 in. (724 mm) 600 Air Pak:
2,040 lb. (925 kg)
Big Blue 600 Air Pak* CV/DC 15–50 V 600 Air Pak: Peak: 15,000 watts D: 69.5 in. (1,765 mm)
907750 Deutz (MIG/FCAW) 500 A at 40 V, 100% duty cycle Continuous: 12,000 watts
907750003 Deutz with WIC 575 A at 43 V, 100% duty cycle
600 A at 44 V, 60% duty cycle
Air Compressor (Air Pak model only) Features Free Air Delivery Working Pressure Constant Duty Cycle Oil Capacity
3
Ingersoll Rand CE55 G1 Rotary screw with electric clutch for on/off, oil change Idle: 40 cfm (1.13 m /min.) 100 psig (7 bar) 100% 4 qt. (3.79 L)
intervals of 500 hours, life expectancy of 30,000 hours Weld: 60 cfm (1.70 m /min.)
3
