GAS EQUIPMENT

Smith Torches See literature GE/24.0 (Hand Cutting Torches), GE/25.0 (Combination Torch Handles) Torches
and GE/26.0 (Combination Torch Attachments)
Stock Head Angle Length
Smith torches are for cutting, heating, welding and brazing. They feature three-tube Number in Degrees Inches (mm)
construction, keeping gases separate in the cutting attachment until mixed at the tip. Gas Axe Extra Heavy-Duty
Cutting Torches
SC925 75 21 (533)
Cutting torches (acetylene, natural gas, LP or
SC929 90 21 (533)
propylene-based fuels) SC935 75 36 (914)
SC939 90 36 (914)
Gas Axe extra-heavy-duty cutting torches are ideal for
™
Gas Axe scrap and demolition cutting. SC930 180 36 (914)
SC929 SC945 75 48 (1,219)
Covered by a one-year warranty SC949 90 48 (1,219)
Reversible-mount (top or bottom) cutting lever SC940 180 48 (1,219)
Thick-wall forged brass head available in three different SC965 75 72 (1,829)
Heavy-duty torches head angles SC969 90 72 (1,829)
SC960 180 72 (1,829)
Hand-tighten only to seat the tip, saving time and tools
when changing tips Heavy-Duty Cutting Torches
SC229 Cuts up to 20 inches (508 mm) with LP and up to SC225 75 20.5 (521)
12 inches (305 mm) with acetylene or propylene SC229 90 20.5 (521)
SC229S* 90 20.5 (521)
Heavy-duty cutting torches are ideal for construction, SC220 180 21 (533)
fabrication and shipyard industries. SC365 75 36 (914)
SC229S SC369 90 36 (914)
Covered by a five-year warranty SC360 180 36 (914)
Reversible-mount (top or bottom) cutting lever
Nickel-plated finish for added corrosion resistance and *Torch head made with thicker-wall
manganese bronze for more severe service.
to reflect residual heat
Heavy-Duty Combination Torches
Hand-tighten only to seat the tip, saving time and tools
when changing tips SC205 75 12.5 (318)
Cuts up to 12 inches (305 mm) SC209 90 12.5 (318)
WH200A Handle 7.5 (191)
Medium-Duty Combination Torches
MC505 75 11.25 (286)
Combination torches (acetylene, natural gas, MC509 90 11.25 (286)
LP or propylene-based fuels) WH100 Handle 7 (178)
SC209 Toughcut Combination Torches
Covered by a five-year warranty (except Toughcut CC509P
™
cutting attachment which has a three-year warranty) CC509P 90 11.25 (286)
WH100 Handle 7 (178)
™
Exclusive Flo-Trol * safety feature protects the cutting
assembly and operator from flashbacks (except Toughcut Standard-Duty Combination Torches
CC509P and standard-duty cutting attachments) AC309 90 8.5 (216)
MC509
WH200A Nickel-plated finish for added corrosion resistance and AW1A Handle 5.75 (146)
to reflect residual heat Machine Torches
Silver-brazed torch joints provide strength, leak-resistance SC772A — 13.75 (349)
and heat protection SC770 — 8 (203)
Triple o-ring seal for easy 360-degree torch head See page 105 for tips and accessories to use
CC509P WH100
rotation to reduce operator fatigue with torches.
Hand-tighten only to seat the tip and attachments,
saving time and tools when changing tips
Heavy-duty torches cut up to 8 inches (203 mm),
AC309 medium-duty and Toughcut up to 6 inches (152 mm),
WH100
and standard-duty up to 3 inches (76 mm)
*Flo-Trol is a spring-loaded back-pressure check valve that prevents burn out
and damage to the cutting assembly by preventing mixed gas from traveling
back into the high-pressure seat area.
AW1A

Machine torches (acetylene, natural gas, LP or
propylene-based fuels)
SC772A
Covered by a five-year warranty
Torch barrels are adjustable to four positions at
90-degree increments and barrel diameters are
1-3/8 inches (9.5 mm) to fit most machines
SC770
Rack pitch is 32, 10 teeth per inch
Cuts up to 12 inches (305 mm)
