GAS EQUIPMENT

Smith Heavy-Duty Outfits and Packs

Combination torch outfits
Outfits include all the components and accessories needed for your cutting, heating, welding or
brazing project.
™
Heavy-duty combination torch with nickel plating to deflect heat, and Flo-Trol safety device which
prevents reverse flow of mixed gases, protecting the cutting assembly and operator from flashbacks
Heavy-duty Series 40 regulators (HBA-40XXX) OR medium-duty Series 30 regulators (HBA-30XXX)
™
™
— with dual filters to protect the seat from debris for reliable operation
Heavy-duty tips with in-tip gas mixing design for safety and resistance to flashback
Graf-Tite soft-seat cutting tips maintain positive seating, eliminating leaks for longer use even if
™
tip is nicked
Torch-mount flashback arrestors (acetylene outfits) OR regulator-mount check valves (propane
outfit) for added safety
Cuts up to 1-1/4 inches (32 mm) with included tips, cuts up to 8 inches (203 mm) with
optional tips
HBA-40510

Combination torch and tips packs
Packs are an easy and economic way to update or change your oxy-fuel system. Available with
cutting, heating and welding tips OR multiple cutting tips.
™
Heavy-duty combination torch with nickel plating to deflect heat, and Flo-Trol safety device which
prevents reverse flow of mixed gases, protecting the cutting assembly and operator from flashbacks
Heavy-duty tips with in-tip gas mixing design for safety and resistance to flashback
™
Graf-Tite soft-seat cutting tips maintain positive seating, eliminating leaks for longer use even if
tip is nicked
Torch-mount flashback arrestors for added safety
Cuts up to 5/8 inch (16 mm) with included tips, cuts up to 8 inches (203 mm) with optional tips
16280

Cutting torch outfits
Outfits include all the components and accessories needed for your cutting, heating, welding or
brazing project.
Heavy-duty hand cutting torch with nickel plating to deflect heat, reversible-mount (top or bottom)
cutting lever, and an ease-on oxygen feature that reduces slag blowback when piercing
™
Heavy-duty Series 40 regulators with gauge guards (HBS outfits) OR medium-duty Series 30 ™
regulators (HBAS outfits) — with dual filters to protect the seat from debris for reliable operation
Heavy-duty cutting tips with in-tip gas mixing design for safety and resistance to flashback
Graf-Tite soft-seat cutting tips maintain positive seating, eliminating leaks for longer use even if
™
tip is nicked
Torch-mount flashback arrestors (HBAS outfits) for added safety
Cuts up to 1-1/4 inches (32 mm) with included tips, cuts up to 12 inches (305 mm) with
HBAS-30510 optional tips
(HBS outfits are not shown, see chart for items included)

Outfit/Pack Stock Number Fuel Oxygen Regulator Fuel Gas Regulator Torch Cut Tip Heat Tip Weld Tip Accessories
Combination HBA-40510 Acetylene 40-175-540 40-15-510 SC209/WH200A SC12-1, SC12-2 ST602 SW205 25 ft. (7.6 m), 1/4 in. (6 mm) “R”-grade hose, lighter,
Torch Outfits shade 5 safety glasses, tip cleaner and flashback arrestors
HBA-40300 40-15-300
HBA-30510 30-100-540 30-15-510 SC209/WH200A SC12-1 ST602 SW205 25 ft. (7.6 m), 1/4 in. (6 mm) “R”-grade hose, lighter,
HBA-30300 30-15-300 shade 5 safety glasses, tip cleaner and flashback arrestors
HBA-30510LP Propane/ 30-100-540 30-50-510 SC209/WH200A SC40-1 ST615 — 20 ft. (6.1 m), 1/4 in. (6 mm) “T”-grade hose, lighter,
natural gas shade 5 safety glasses, tip cleaner and check valves
Combination Torch 16206 Acetylene — — SC209/WH200A SC12-1 ST602 SW203 H743 flashback arrestors
and Tips Packs
16280 SC12-0, SC12-1 — —
Cutting Torch HBS-H510S Acetylene 40-175-540S 40-15-510S SC229 SC12-2 — — Hard Hat ™ gauge guards
Outfits (denoted by “S” designation at end of regulator number)
HBS-H300S 40-15-300S
HBAS-30510 30-100-540 30-15-510 SC229 SC12-1 — — 20 ft. (6.1 m), 3/16 in. (5 mm) “R”-grade hose, lighter,
HBAS-30300 30-15-300 shade 5 safety glasses, tip cleaner and flashback arrestors
