For more detailed
SAFETY AND HEALTH MillerWelds.com/safety
information, visit

Safety products designed to Level 1
Process Modification/
protect welders and enhance Substitution

Level 2
their long-term performance Engineering

The Miller focus has always been welding — understanding welders, Increasing Effectiveness Controls
their needs and the safety products used within their work environments. Level 3
We provide multiple solutions for weld fume control that fulfill each level of OSHA’s Work Practice
Controls
hierarchy of controls. We will help you get maximum productivity out of each welder
while keeping them comfortable and improving compliance. Our complete line of
Weld Environment, Head and Face, and Hand and Body protection is designed to Level 4
perform in demanding welding, cutting and grinding applications. Personal Protective
Equipment

OSHA 29 CFR 1910.134

Our line of FILTAIR® fume extractors are designed specifically for welding — drawing weld fumes away from the user’s
Fume Extractors breathing zone and helping keep your facility clean. We offer many types of fume extraction equipment to best fit your
environment. Visit MillerWelds.com/filtair for more information.
FILTAIR 130 (page 106) 215 (page 107) MWX (page 108) Capture 5 (page 108) SWX (page 109) 4000–12000 (page 110)
Weld Fume Portable, high-vacuum Mobile, high-vacuum Mobile, low-vacuum Mobile, low-vacuum with up Stationary, low-vacuum suited Centralized, low-vacuum
Extractor Type to a five-foot capture zone for wall or column mounting customizable systems
Ideal For Contractors, maintenance Heavy industrial fabrication Fabrication shops, Manufacturing and Fabrication shops, Manufacturing, hand-held and
and repair operations, and fume guns/long manufacturing, and fabrication — the best manufacturing, and training automation, fabrication shops,
light fabrication work and distance extraction training centers solution for weldments over centers where weld areas are and training facilities
light manufacturing 18 inches long near filtration system
ZoneFlow ™ — — — Standard (see page 110) Option (see page 110) Option (see page 110)
Technology
Welding Arcs 1 Up to 4 per unit 1 1 Up to 2 per unit Up to 18 per unit
Filter Type Manual cleaning Self-cleaning MWX-D: Disposable Self-cleaning (automatic) SWX-D: Disposable Self-cleaning
MWX-S: Self-cleaning SWX-S: Self-cleaning (automatic/programmable)

® Processes
FILTAIR 130 See literature AY/3.1 Stick (SMAW) Flux-cored (FCAW)
MIG (GMAW) TIG (GTAW)
Comes with
Portable, high-vacuum weld fume extractor designed for
FilTek® XL filter
use with accessories like nozzles and fume guns to collect 8 ft. (2.4 m) collection hose
weld fume particulate at the source. 20 ft. (6 m) power cord
Most popular consumables
FilTek XL Filter 301267
Superior filters. The MERV 15 rating of our FilTek XL filters provides
Most popular accessories
superior filtering of up to 95 percent of weld fume particulate.
™
Bernard® Clean Air Fume Extraction
Excellent filtering performance. Weld fume particulate is captured with MIG Gun (pg 27)
a cleanable filter and deposited in the integrated particulate bin. Collection Hose
300896 17 ft. (5.2 m)
Airflow of 132 cfm with variable flow control to adequately capture
300897 34 ft. (10.4 m)
fume with fume guns or nozzle.
Slotted Magnetic
Less noise. Only 68.5 decibels at five feet. Nozzle 300895
12 in. (305 mm) width
12 in. (305 mm) width
Portable and compact. At only 46 pounds (21 kg) the vertical-shaped
machine is easy to move around.
Flexible Funnel Magnetic Nozzle
300668
Stock Number Filter Media Nominal Airflow Sound Level Motor Input Power Dimensions Net Weight
300595 31 sq. ft. (2.88 sq. m) 132 cfm (62 L/sec.) 68.5 dBA at 5 ft. (1.5 m) 1.27 kW 115 V, 1-phase, 60 Hz at 11.25 A H: 23 in. (584 mm) 46 lb. (21 kg)
951860 With flexible funnel W: 12 in. (305 mm)
magnetic nozzle D: 12 in. (305 mm)
106
