GAS EQUIPMENT

™
Smith Toughcut Outfits See literature GE/10.0

Outfits include all the components and
accessories needed for your cutting, heating,
welding or brazing project. Tag-A-Long outfits
add portable carrier that houses 10–20 cu. ft.
cylinders.
Toughcut combination torch with nickel-plating
to deflect heat
™
Medium-duty Series 30 regulators with
dual filters to protect the seat from debris for
reliable operation
Medium-duty tips with in-tip gas mixing design
for safety and resistance to flashback
Graf-Tite soft-seat cutting tips maintain
™
positive seating, eliminating leaks for longer
use even if tip is nicked
Regulator-mount check valves for added safety
and torch life
MB55A-510 and MB55A-300 cut up to
5/8 inch (16 mm) with included tip,
TL-500 and TL-550 cut up to 3/8 inch (10 mm)
with included tip, all outfits cut up to 6 inches
MB55A-300 TL-550 (Tag-A-Long) includes
portable carrier for 10–20 cu. ft. cylinders. (153 mm) with optional tips

Outfit Stock Number Fuel Oxygen Regulator Fuel Gas Regulator Torch Cut Tip Heat Tip Weld Tip Accessories
Combination Torch Outfits MB55A-510 Acetylene 30-100-540 30-15-510 CC509P/WH100 MC12-1 MT603 MW205 20 ft. (6.1 m), 3/16 in. (5 mm) “R”-grade hose,
lighter, shade 5 safety glasses and check valves
MB55A-300 30-15-300
Combination Torch TL-500 (no tanks) Acetylene 30-100-540 30-15-200 CC509P/WH100 MC12-0 — MW203 Carrier, 12.5 ft. (3.8 m), 3/16 in. (5 mm)
Portable Tag-A-Long Outfits TL-550 “R”-grade hose, lighter, shade 5 safety glasses,
check valves, oxygen cylinder and acetylene
cylinder (cylinders NOT included with TL-500)

®
Smith Versa-Torch Standard-Duty Outfit

Lightweight and compact outfit for easy handling in confined spaces. Portable carrier houses
10–20 cu. ft. cylinders. A broad selection of cutting, welding and specialty attachments
®
(see page 105) makes the Versa-Torch ideal for air conditioning, refrigeration, plumbing,
metal fabrication, jewelry, metal sculpture, maintenance and repair.
Standard-duty combination torch with nickel-plating to deflect heat
™
Medium-duty Series 30 regulators with dual filters to protect the seat from debris for
reliable operation
Medium-duty tips with in-tip gas mixing design for safety and resistance to flashback
Graf-Tite soft-seat cutting tip maintains positive seating, eliminating leaks for longer use even
™
if tip is nicked
Regulator-mount check valves for added safety and torch life
Compatible with MC12-00 to MC12-4 medium-duty cutting tips
Cuts up to 3/16 inch (5 mm) with included tip, cuts up to 4 inches (102 mm) with optional tips

Stock Number Fuel Oxygen Regulator Fuel Gas Regulator Torch Cut Tip Mixer Tube Heat Tip End Braze Tip Accessories
VT-4T Acetylene 30-100-540 30-15-200 AC309/AW1A MC12-00 AT60 13716 LT103, LT104, LT106 Carrier, 12.5 ft. (3.8 m), 3/16 in. (5 mm) “R”-grade hose,
Rosebud lighter, shade 5 safety glasses, check valves, oxygen
cylinder and acetylene cylinder
