WIRE FEEDERS BENCH

20 Series and

74 MPa Plus

Heavy-Industrial
Bench Feeders

Designed for manufacturing,
our popular bench feeders
are available in two series
with multiple models to fit
D-74 MPa Plus
your needs. S-74 MPa Plus
20 Series Digital
20 Series Basic
20 Series and 74 MPa Plus Features
Feeders include a 10 ft. interconnecting
20 Series
cord and are available with drive rolls
Feature Basic Digital 74 MPa Plus
and a Bernard BTB Gun 400 A (two with
Available w/Bernard® gun: dual-wire models, see chart on page 19).
BTB Gun 400 A
Trigger hold
Digital meter(s)
Remote voltage control
Adjustable run-in control
Automatic run-in control TM 20 Series and 74 MPa Plus wire feeders with a Bernard BTB Gun include
Dual-wire models Accu L ck
™
Rotatable drive assembly AccuLock consumables (see chart on page 19).
Accu-Mate ™ Trigger hold allows the operator to make long welds without having to hold the trigger continuously.
Preflow/postflow
Spot control Reduces operator fatigue.
Dual schedule control
Trigger program select Miller® standard quick-change drive rolls save time.
Trigger dual schedule Quick-release drive-roll pressure arm allows drive roll change without losing spring preload setting.
Sequence control
Locks and limits Easy loading and threading of welding wire without having to release the drive roll pressure arm.
Weld programs 4
Trigger schedule select Four gear-driven drive rolls provide more consistent feeding on larger wire diameters.
Push-pull capability
Synergic pulsed MIG
Profile Pulse ™
Standard Field option

20 Series (Basic and Digital) See literature M/11.0
Simple and cost-effective feeders for heavy-industrial manufacturing and fabricating.

Ideal for most high-duty-cycle applications requiring day-in/day-out Digital meter (standard on digital model, field option on basic model)
trouble-free operation. ensures accuracy when presetting and reading actual voltage, amperage and
On-board burnback and motor ramp control for excellent starting and wire feed speed.
stopping performance. Remote voltage control (standard on digital model, field option on
basic model) at feeder for easier adjustments in the weld cell.
Adjustable run-in control (standard on digital model, field option on
basic model) for better arc-starting performance on a variety of wires.

18
