PORTABLE WIRE FEEDERS

Heavy industrial
®
ArcReach 16 Use with CC/CV, DC power sources.
Portable Feeder Processes
MIG (GMAW) Flux-cored (FCAW)
See literature DC/18.98 Air carbon arc cutting and gouging
(CAC-A) (rated 3/8 in. carbons) with
XMT 650 power source
Portable feeder that takes Suggested power sources
XMT® 650 Series (pg 50)
productivity, cost savings, Note: ArcReach 16 feeder is compatible with
and power to the next standard power sources and engine-driven
welders, but functions as standard equipment
level for structural steel without remote control capabilities unless
fabrication and erection. paired with an ArcReach power source. Full
functionality of ArcReach is only available
with XMT 650 ArcReach power source.
Suggested guns
ArcReach 16 Features Bernard® BTB Gun 400 A (pg 26)
Feature
Available with Bernard® gun:
BTB Gun 400 A
IronPro ™ Bernard® IronPro GL4515MLNM
™
Remote voltage control ArcReach 16
(without a cord) with field roller (pg 27)
Gouge ArcReach 16 with shop cart Self-shielded flux-cored gun designed
Digital meters for ironworkers and structural steel
Gas purge erectors to excel in the outdoors with
Wire jog large-diameter wire up to 3/32 inch
Feeds 3/32 in. wire Feeders are available with drive rolls
Available with shop cart or field roller — sealed trigger remains slag and
and a Bernard gun (see chart below). spatter free for extended life and
Bernard BTB Gun 400 A shown. ergonomic design provides excellent
access and maneuverability for
hard-to-reach weld joints
Most popular accessories
Inline Filter 211989
Accu L ck TM ArcReach 16 wire feeders with Voltage-sensing feeder designed to run on arc Spool Cover Hanger Kit 295877
a Bernard BTB or IronPro gun
voltage. The ArcReach 16 operates on the arc voltage
Wire Reel Assembly 108008
include AccuLock consumables (see chart below). of almost any power source, but is best paired with an Visit MillerWelds.com or your distributor
™
Remote control of the power XMT 650 model (page 50). for other Miller®options and accessories.
source without a cord. With Weld with up to 60-pound spools and large
an ArcReach 16 feeder and ArcReach power source diameter (3/32 in.) wire to minimize downtime and
you can change output voltage at the feeder, and maximize productivity.
save a trip to the power supply. No extra control cord Easy mobility in the shop and on-site (optional shop
to purchase, maintain, string or unstring — saving time cart and field roller). The ArcReach 16 wire feeder
and money. preassembled options include a shop cart and a
Easy process changeover. Simply connect the field roller.
ArcReach 16 wire feeder to your weld lead and you Shop cart provides easy shop mobility with low
are ready to go. Switch between welding and gouging clearance. Handle doubles as a cable holder.
with a push of a button with no need to swap leads Field roller provides easy field mobility over pan
or disconnect the wire feeder with isolated outputs. decking and other surfaces. Designed for the
Integrated gouging stud on wire feeder. Isolated environment with spool cover and IP23 rating.
gouging stud allows easy connection for gouging at Includes spool cover, hanging bail and cable holder.
point of use, eliminating the need to disconnect the
wire feeder and to swap leads.

Input Welding Wire Type and Max. Spool
Stock Number Input Power Circuit Rating Wire Feed Speed Diameter Capacity Size Capacity Dimensions (H x W x D) Net Weight
301619 Base feeder only
18 in. (457 mm)
Base feeder
Base feeder
Solid wire
50–780 ipm
450 A at
Operates on
ArcReach 301664 With shop cart open-circuit 100% duty cycle (1.3–19.8 m/min.) .035–5/64 in. 60 lb. (27.2 kg) 15.3 x 16.7 x 32.8 in. (388 x 424 x 833 mm) 101 lb. (45.8 kg)
voltage and
dependent on
(0.9–1.9 mm)
951000065 With shop cart and
Shop cart
500 A at
Shop cart
arc voltage:
arc voltage
Bernard BTB Gun 400 A
Flux-cored
120 lb. (54.4 kg)
60% duty cycle
20 x 24.9 x 36.3 in. (508 x 632 x 922 mm)
301663 With field roller
951000066 With field roller and 12–110 VDC CAC-A .045–3/32 in. Field roller Field roller
(1.1–2.4 mm)
28.2 x 19.9 x 42.7 in. (716 x 505 x 1,084 mm)
123 lb. (55.7 kg)
600 A at
Bernard IronPro gun
40% duty cycle
