For more detailed
WIRE FEEDERS MillerWelds.com/wirefeeders
information, visit

Also see MIG, MIG Guns and Multiprocess sections for wire feeding options.

Product Pulsed MIG 1 Power Source Wire Types
Flux-cored
Guide Page Class MIG RMD® 1 Flux-cored 2 Gouge Required Solid Gas-shld Self-shld Alum. Wire Diameter
Capacity Special Features Typical Applications
ArcReach® 16 15 3 CC/CV .035–3/32 in. 60 lb. spool capacity, powered by arc voltage, remote Structural steel,
(0.9–2.4 mm) voltage and process control without a control cord, fabrication, erection
optimized with XMT® 650 ArcReach power sources,
large diameter 3/32 in. wire, isolated gouge stud,
available with shop cart or IP23-rated field roller
ArcReach® SuitCase® 16 CC/CV CV 2 .023–5/64 in. 8 in. (SuitCase 8) or 12 in. (SuitCase 12) diameter spool Construction,
(8 and 12) (0.6–2.0 mm) capacity, powered by arc voltage, remote voltage control site fabrication,
Portable Heavy Duty model:
without a control cord with ArcReach power sources. field maintenance
ArcReach Suitcase 12 Heavy Duty model available for
.030–3/32 in.
use with large diameter 3/32 in. cored wire
(0.8–2.4 mm)
ArcReach® 16 ArcReach .035–.045 in. 12 in. diameter spool capacity, remote voltage control Process piping,
Smart Feeder equipped (0.9–1.1 mm) without a control cord, requires an XMT 350 FieldPro refinery, petrochemical,
connected to three-phase power or a compatible power plants, HVAC,
ArcReach-equipped engine drive water pipe
SuitCase® 12RC 16 CV .023–5/64 in. 12 in. diameter spool capacity, standard remote voltage Field maintenance,
(0.6–2.0 mm) control, powered by 14-pin control cord site fabrication
20 Series 18 CV .023–5/64 in. Four quick-change drive rolls, digital meter, Manufacturing,
(Basic and Digital) (0.6–2.0 mm) remote voltage control (meter and remote voltage fabrication
control are a field kit option on basic model)
.023–5/64 in. Sequence control, locks and limits, four weld program Manufacturing requiring
Bench 74 MPa Plus 18 CV (0.6–2.0 mm) memories, synergic pulsed MIG with MPa power sources, multiple wire types
(Single- and Dual-Wire)
XR-Aluma-Pro ™ Plus or XR ™ -Pistol Plus guns for feeding
soft wires are designed to work with MPa Plus feeders
74 MPa Plus 20 CV .023–5/64 in. Control box, cables and wire drive motor assemblies for Heavy and light
Remote Configurations (0.6–2.0 mm) generic booms or fixed automation manufacturing,
(Single- and Dual-Wire) fabrication
Product Key Class: Light industrial Industrial Heavy industrial Capability: Designed for this process Capable of this process
1 Smart Feeder requires an XMT®350 FieldPro ™ connected to three-phase power or a compatible ArcReach-equipped engine drive. All other feeders require an MPa inverter power source.
2 Certain self-shielded wires require CV output. Miller recommends a CV power source whenever possible.
3 ArcReach 16 requires an XMT®650 power source to gouge.
