ADVANCED/AUTOMATED GMAW MIG

Heavy industrial
™
Auto-Continuum Systems See literature AU/10.0
Processes
Next generation automation welding solution delivers advanced arc performance to improve Accu-Pulse® MIG (GMAW-P)
Versa-Pulse ™ RMD ® MIG (GMAW)
throughput and weld quality. High-deposition MIG (GMAW)
Flux-cored (FCAW)
Most popular accessories
More power — better reliability. Up to 26 percent Insight Centerpoint ™ Software (pg 75)
more welding output (than competitive models) for Auto-Continuum Robotic MIG Kit
demanding industrial applications. 301455
Consists of 25 ft. (7.6 m) motor
Allows for any input control cable, 15 ft. (4.6 m)
voltage hookup 90-degree motor control extension
(230–575 V, three-phase) with no manual linking, cable, 15 ft. (4.6 m) weld cable,
providing convenience in any job setting. Ideal flowmeter regulator, 30 ft. (9.1 m)
gas hose, 9.8 ft. (3 m) Ethernet
solution for dirty or unreliable power.
cable, .035/.045-inch V-groove drive
Improve work environment and reduce spatter. roll kit with guides, 30 ft. (9.1 m)
Versa-Pulse and Accu-Pulse processes reduce weld wire conduit assembly, and
10 ft. (3 m) conduit and clamps
fume generation, and by precisely controlling the
(for mounting motor control cable,
welding arc they also reduce spatter size and
weld cable and gas hose)
quantity. Fume generation can be reduced up to Wire Drive Motor Mounting Brackets
50 percent over traditional CV MIG. 300013 FANUC®/KUKA®/Motoman®
Versa-Pulse is a fast, low-heat, low-spatter 300483 FANUC®100 and 120 IC
Continuum Integrated Cooler 301214
process for high-speed automation on thin Mounts to bottom of power source —
materials and is great for gap filling.
does not require external power
Accu-Pulse is better for out-of-position welds, Motor/Control Cables
provides higher deposition rates and is designed 263368025 25 ft. (7.6 m)
Auto-Continuum for thicker materials than Versa-Pulse. 263368050 50 ft. (15 m)
500 shown 263368080 80 ft. (24.4 m)
with robot arm Easy communication from robot to power source.
(not included) and 263368100 100 ft. (30.5 m)
Auto-Continuum Designed for easy integration with fixed and 90-degree Motor Control Extension
wire drive motor Cables
assembly. flexible automation. 281554015 15 ft. (4.6 m)
Fleet standardization. Auto-Continuum can be used 281554025 25 ft. (7.6 m)
EtherNet/IP ™ Communication Cables
for both automation and hand-held applications.
300734 9.8 ft. (3 m)
Welding Intelligence. Get more done, produce 300736 32.8 ft. (10 m)
™
higher-quality welds and control costs. DeviceNet Communication Cable
300021 20 ft. (6.1 m)
Insight Core (standard) gives owners/managers DeviceNet to Analog Adapter
™
visibility of welder productivity, so they can
Close-up of Auto-Continuum 301547
wire drive motor assembly make informed decisions to drive improvements Visit MillerWelds.com or your distributor
(left-hand drive). (see page 74). for other Miller®options and accessories.
Insight Centerpoint (optional) gives real-time
™
guidance to welders, so less training is required
and weld quality is improved (see page 75).

*While idling.
Amp/Volt Amps Input at Rated Output, 50/60 Hz, 3-Phase Max. Open- Dimensions
Model/Stock Number Ranges Rated Output 230 V 380 V 400 V 460 V 575 V KVA KW Circuit Voltage (Includes lift eye) Net Weight
Auto-Continuum 350 20–400 A 350 A at 31.5 VDC, 36.7 21.8 20.8 18.8 14.6 14.4 13.8 72 VDC H: 27.187 in. (691 mm) 130 lb.
907656 10–44 V 100% duty cycle 0–1* 0–1* 0–1* 0–1* 0–1* 0.8* 0.17* W: 17.5 in. (444 mm) (59.4 kg)
907658 With auxiliary power D: 28.22 in. (717 mm)
Auto-Continuum 500 20–600 A 500 A at 39 VDC, 57.6 34.7 33.2 28.9 23.3 23.1 21.9 72 VDC 150 lb.
907657 10–44 V 100% duty cycle 0–1* 0–1* 0–1* 0–1* 0–1* 0.8* 0.17* (69 kg)
907659 With auxiliary power
Model/Stock Number Input Power Input Welding Circuit Rating Wire Feed Speed Wire Diameter Capacity Dimensions Net Weight
Auto-Continuum Wire Drive Motor Assembly 50 VDC 500 A at 100% duty cycle Standard: .035–5/64 in. H: 8.75 in. (222 mm) 16.5 lb. (7.5 kg)
301207 Left-hand drive 50–1,000 ipm (0.9–2.0 mm) W: 10 in. (254 mm)
(1.3–25.4 m/min.) D: 10 in. (254 mm)
13
