PORTABLE WIRE FEEDERS

Heavy industrial
ArcReach SuitCase 8 and 12 and ArcReach Smart Feeder Use with CC/CV (CV only with 12RC),
®
®
DC power sources. See spec chart below
See literature M/6.55
for Smart Feeder requirements.
Processes
Remote control MIG (GMAW) Flux-cored (FCAW)
of the power source without a cord. RMD and pulsed MIG (GMAW-P)
With an ArcReach SuitCase feeder ArcReach with ArcReach Smart Feeder
and ArcReach power source you can feeder or Suggested power sources
change output voltage at the feeder, remote Note: ArcReach SuitCase feeders are
compatible with standard power sources
and save a trip to the power supply.
and engine-driven welders, but function as
No extra control cord to purchase, standard equipment without remote control
maintain, string or unstring — saving capabilities. Full functionality of ArcReach is
only available with ArcReach power sources.
time and money. See pages 48–50
For ArcReach SuitCase 8 and 12
and 80–87 for ArcReach power
Maxstar® 280 Multiprocess (pg 45)
sources and engine drives. Dynasty® 300 Multiprocess (pg 45)
ArcReach
Easy process changeover. Simply power source XMT® Series (pg 46–50)
connect the ArcReach feeder to your Bobcat ™ Series (pg 79–81)
Trailblazer® Series (pg 82–84)
leads and you are ready to go. All
Big Blue® Series (pg 84–87)
controls automatically shift to the
For ArcReach Smart Feeder
ArcReach feeder. XMT® 350 FieldPro ™ (pg 48)
Voltage-sensing feeders designed to run on arc voltage. The ArcReach SuitCase 8 and 12 operate on the (requires three-phase power)
Big Blue® Series
arc voltage of almost any power source. The ArcReach Smart Feeder requires an XMT 350 FieldPro (page 48)
®
™
(ArcReach models only) (pg 84–87)
connected to three-phase power or a compatible ArcReach-equipped engine drive (pages 84–87).
For SuitCase 12RC
Weld with large diameter wire. The ArcReach SuitCase 12 Heavy Duty model is specifically designed for (requires power source with compatible
applications using 3/32-inch cored wire. 14-pin connector)
XMT® Series (pg 46, 50)
Trailblazer® Series (pg 82–84)
Additional features of ArcReach Smart Feeder
Big Blue® Series (pg 84–87)
®
Delivers excellent synergic RMD and pulsed MIG welding up Suggested guns
to 200 feet away from the power source with no control cords — Bernard® Guns (pg 26–27)
twice the distance previously possible. RMD and pulsed MIG Most popular accessories
welding permits procedures with one wire and one gas to eliminate Extension Cables (pg 130)
process switch-over time. RMD and pulsed MIG processes also help (for SuitCase 12RC only, 1 required)
RMD carbon steel
reduce weld failures and eliminate backing gas on some stainless Flowmeter Kit 300343
and chrome-moly applications. Shielding Gas Filter 195189
Pulsed MIG stainless
Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
®
SuitCase 12RC See literature M/6.5
Standard remote voltage control with a control cord. For applications where the feeder is within 100 feet of the
power source and control cords are acceptable.
*Additional packages are available — visit MillerWelds.com or your distributor.
Input Welding Maximum Spool Net
Model Stock Number* Input Power Circuit Rating Wire Feed Speed Wire Type and Diameter Capacity Size Capacity Dimensions Weight
ArcReach 951726001 w/Bernard BTB Gun 300 A Operates on 330 A at 50–780 ipm Solid wire .023–.052 in. (0.6–1.4 mm) 8 in. (203 mm), H: 12.75 in. (324 mm) 28 lb.
SuitCase 8 951727 w/Bernard S-Gun open-circuit voltage 60% duty cycle (1.3–19.8 m/min.) Flux-cored .030–5/64 in. (0.8–2.0 mm) 14 lb. (6.4 kg) W: 7.25 in. (184 mm) (13 kg)
951728 w/Bernard Dura-Flux gun and arc voltage: dependent on D: 18 in. (457 mm)
301457 Feeder only 14–48 VDC/ arc voltage
ArcReach 951729001 w/Bernard BTB Gun 300 A 110 max. OCV 425 A at Solid wire .023–.052 in. (0.6–1.4 mm) 12 in. (305 mm), H: 15.5 in. (394 mm) 35 lb.
SuitCase 12 951730 w/Bernard S-Gun 60% duty cycle Flux-cored .030–5/64 in. (0.8–2.0 mm) 45 lb. (20 kg) W: 9 in. (229 mm) (15.9 kg)
951731 w/Bernard Dura-Flux gun D: 21 in. (533 mm)
951732 w/Bernard PipeWorx 300-15 gun
ArcReach ArcReach 301456 Feeder only 450 A at 30–400 ipm Flux-cored .030–3/32 in. (0.8–2.4 mm) 12 in. (305 mm), H: 15.5 in. (394 mm) 35 lb.
951000096 w/Bernard IronPro gun
SuitCase 12
D: 21 in. (533 mm)
Heavy Duty 301604 Feeder only 60% duty cycle (0.8–10.2 m/min.) 45 lb. (20 kg) W: 9 in. (229 mm) (15.9 kg)
dependent on
arc voltage
ArcReach 951733 w/Bernard PipeWorx gun XMT 350 FieldPro 275 A at 50–500 ipm .035–.045 in. (0.9–1.1 mm) 12 in. (305 mm), H: 18 in. (457 mm) 50 lb.
Smart 300935 Feeder only connected to three- 60% duty cycle (1.3–12.7 m/min.) 33 lb. (15 kg) W: 13 in. (330 mm) (23 kg)
Feeder phase power or a dependent on D: 21.5 in. (546 mm)
compatible ArcReach- arc voltage
equipped engine drive
SuitCase 951580001 w/Bernard BTB Gun 300 A 24 VAC, 10 A, 425 A at 50–700 ipm Solid wire .023–.052 in. (0.6–1.4 mm) 12 in. (305 mm), H: 15.5 in. (394 mm) 31 lb.
12RC 301121 Feeder only 50/60 Hz 60% duty cycle (1.3–17.8 m/min.) Flux-cored .030–5/64 in. (0.8–2.0 mm) 45 lb. (20 kg) W: 9 in. (229 mm) (14.1 kg)
D: 21 in. (533 mm)
