BENCH WIRE FEEDERS

Heavy industrial
74 MPa Plus See literature M/3.0 Use with CV, DC power sources.
Feeders for heavy-duty industrial applications with features for weld control and programs, plus Processes
MIG (GMAW) Flux-cored (FCAW)
push-pull aluminum capabilities. Optimized with AlumaPower MPa or XMT ® MPa power sources.
™
Pulsed MIG (GMAW-P) with MPa Plus
feeder and MPa power source
Available in dual-wire models which allow two different Recommended
wire types to be available on one feeder, avoiding aluminum Suggested power sources
™
AlumaPower MPa (pg 9)
downtime from changing spools and drive rolls. solution.
XMT® Series (pg 46–50)
Toolless rotatable drive assembly allows operator to rotate XR Plus guns Suggested guns
the drive housing, allowing a straight path for wire flow. (gooseneck and Bernard® Guns (pg 26–27)
pistol grip) are designed to
™
Accu-Mate properly seats the MIG gun power pin for work with MPa Plus feeders XR-Aluma-Pro ™ Plus and XR -Pistol
™
best feeding performance. Plus (see chart below)
to coordinate wire feed
High-torque permanent-magnet motor, sealed ball speed of the gun and the feeder. This provides Most popular accessories
Feeder Cart 142382 (pg 122)
bearing gear drive and solid-state speed and brake optimized aluminum feeding and welding performance. Extension Cables (pg 130)
control are maintenance free for long life. See chart below for gun models and stock numbers. Spool Adapter 047141 (pg 130)
Digital meters ensure accuracy when presetting and Turntable Assembly 146236
reading actual voltage, amperage and wire feed speed. Additional features when used with (pg 130)
AlumaPower MPa or XMT MPa power sources Wire Straightener (pg 130)
Remote voltage control allows you to set both voltage Field Kits for 20 Series Basic
and wire feed speed at the feeder, saving time and Synergic pulsed MIG. As wire speed increases/decreases, 301513 Digital meter and
increasing weld quality. pulse parameters also increase/decrease to match the remote voltage control
right amount of power needed, reducing the need to 301515 Run-in control
Adjustable run-in control for improved arc starts.
make additional adjustments. Hanging Bail 058435
Dual schedule control allows the operator to switch Spool Covers
™
Profile Pulse provides
between two preconfigured welding parameters 057607 For 20 Series and 74 MPa
TIG appearance with MIG Plus single-wire models
without readjusting the machine, saving time and
simplicity and productivity. and left side of
enhancing quality.
Achieve “stacked dimes” dual-wire models
Trigger schedule select saves time when switching 090389 For right side of 74 MPa
without gun manipulation. Profile Pulse frequency
between two weld settings by simply tapping gun trigger. Plus dual-wire models
can be changed to increase or decrease the spacing
Wire Reel Assembly 108008
Trigger program select provides the ability to access between the ripple pattern to achieve the desired Remote configurations are available —
any of the four active programs. weld appearance. see page 20 and literature M/3.0
Sequence control gives the operator the ability to Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
adjust all of the welding parameters: preflow, run-in,
weld time, crater, burnback and postflow.
Locks and limits for restricting or limiting operator
adjust ments, such as voltage and wire feed speed
parameters.
Four weld program memories allow operators to
recall up to four previously used processes and their
weld settings.
Push-pull capability provides consistent, versatile and
dependable aluminum wire feeding over greater distances.
*Additional packages are available — visit MillerWelds.com or your distributor. **Requires gun wire kit (230708) to run 1/16 in. (1.6 mm) wire.
Input Maximum Spool
Model Stock Number* Power Wire Feed Speed Wire Type and Diameter Capacity Size Capacity Dimensions Net Weight
20 Series 301499 Basic feeder only 24 VAC, 75–750 ipm .023–5/64 in. (0.6–2.0 mm) 60 lb. (27 kg) H: 16 in. (406 mm) 46 lb. (21 kg)
951779001 Basic feeder w/Bernard BTB Gun 400 A 3.5 A, (1.9–19 m/min.) coil with optional W: 12.375 in. (314 mm)
50/60 Hz wire reel assembly D: 27.875 in. (708 mm)
301499001 Digital feeder only
951780001 Digital feeder w/Bernard BTB Gun 400 A (108008)
74 MPa Plus 951291001 S-74 MPa Plus single-wire feeder 24 VAC, 50–780 ipm Solid wire .023–5/64 in. (0.6–2.0 mm) 60 lb. (27 kg) H: 14 in. (356 mm) 48 lb. (21.2 kg)
w/Bernard BTB Gun 400 A 10 A, (1.3–19.8 m/min.) Aluminum** .035–1/16 in. (0.9–1.6 mm) coil with optional W: 12.5 in. (318 mm)
50/60 Hz wire reel assembly D: 28 in. (711 mm)
(108008)
951292001 D-74 MPa Plus dual-wire feeder H: 14 in. (356 mm) 87 lb. (39.5 kg)
w/two Bernard BTB Gun 400 A W: 21 in. (533 mm)
D: 35 in. (889 mm)
Cable Length Wire Type and Gun Only
Optional Push-Pull Gun 15 ft. (4.6 m) 25 ft. (7.6 m) 35 ft. (10.7 m) Welding Current Rating Wire Feed Speed Diameter Capacity Dimensions Net Weight
XR-Aluma-Pro Plus (Air-cooled) 301575 301574 301739 300 A at 100% duty cycle 70–780 ipm Aluminum** H: 5 in. (127 mm) 2.5 lb. (1.1 kg)
(1.8–19.8 m/min.) .030–1/16 in. (0.8–1.6 mm) W: 2.5 in. (64 mm)
XR-Aluma-Pro Plus (Water-cooled) 301576 301577 301740 400 A at 100% duty cycle 2.9 lb. (1.3 kg)
L: 17 in. (432 mm)
XR-Pistol Plus (Air-cooled) 300753 300754 — 200 A at 100% duty cycle 70–780 ipm Aluminum** H: 7.375 in. (187 mm) 2.2 lb. (1 kg)
(1.8–19.8 m/min.) .030–1/16 in. (0.8–1.6 mm) W: 1.875 in. (48 mm)
XR-Pistol Plus (Water-cooled) — 300757 — 400 A at 100% duty cycle L: 10.625 in. (270 mm) 2.4 lb. (1.1 kg)
