MULTIPROCESS

® Light industrial
Multimatic 215 See literature DC/12.59
Processes
MIG (GMAW) Flux-cored (FCAW)
DC stick (SMAW) DC TIG (DC GTAW)
Comes complete with
™
10 ft. (3 m) 100-amp MDX -100
MIG gun with AccuLock ™ MDX ™
consumables
13 ft. (4 m) cable with electrode holder
and 25 mm Dinse-style connector
10 ft. (3 m) work cable with clamp
Multi-voltage plug and 25 mm Dinse-style connector
(MVP ™ ) allows 6.5 ft. (2 m) power cord with MVP
connection to plugs for 120 V and 240 V
common 120- and 240-volt Quick Select ™ drive roll for
power receptacles without the .024 in. (0.6 mm) or .030/.035 in.
use of any tools — simply choose
(0.8/0.9 mm) solid wire, and
the plug that fits the receptacle
and connect to the power cord. .030/.035 in. (0.8/0.9 mm)
flux-cored wire

Welding Capability Intuitive color LCD interface
makes it quick and easy to
Max. 3/8 in. (9.5 mm) Max. 3/8 in. (9.5 mm)
adjust parameters.
MIG MIG Flow gauge regulator and gas hose
™
Mild Steel Aluminum Auto-Set Elite can be used for argon or AR/CO 2 mix, extra MDX
on multiple materials and contact tips, Hobart® spool of .030 in.
Min. 24 ga. (0.6 mm) Min. 18 ga. (1.2 mm)
multiple processes with the solid wire, hook-and-loop cord wraps,
Max. 3/8 in. (9.5 mm) information/settings chart and
ability to fine-tune your settings. Easy to set up and use!
material thickness gauge (229895)
Max. 3/16 in. (4.8 mm) Stick Weighing only 38 pounds, this lightweight MIG, stick and TIG welder
Mild Steel Most popular accessories
TIG Mild Steel
provides portability on the job. Spoolmate Spool Guns (pg 28)
™
Min. 24 ga. (0.6 mm) Min. 16 ga. (1.5 mm)
Angled cast-aluminum drive system with calibrated tension knob 300371 Spoolmate 100
Aluminum welding uses optional Spoolmate 100 creates consistent feeding and easy setup. 301272 Spoolmate 150
and 4000 series aluminum wire OR Spoolmate 150 Running Gear/Cylinder Rack
and either 4000 or 5000 series aluminum wire. Excellent arc characteristics! Positive arc starts and an extremely 301239 (pg 122)
TIG welding uses optional TIG contractor kit. stable arc with minimal spatter. Protective Cover 301262 (pg 125)
TIG Contractor Kit 301337 (pg 128)
™
Quick Select drive roll makes setup quicker by offering three grooves
Visit MillerWelds.com or your distributor
— two for different size solid wire and a third for flux-cored wire. for other Miller®options and accessories.
™
Auto Spool Gun Detect automatically detects when a MIG gun or
spool gun is connected, eliminating the need for a switch.
Fan-On-Demand cooling system only operates when needed, reducing
™
power consumption and keeping internal components cleaner.
Thermal overload protection shuts down unit if airflow is blocked or
duty cycle is exceeded. Automatically resets when unit cools.
Uses 4- or 8-inch (102 or 203 mm) spools.

Stock Number Welding Input Amperage Amps Input at Rated Output, 50/60 Hz Max. Open- Net
907693 Mode/Process Power Range Rated Output 120 V 240 V KVA KW Wire Feed Speed Circuit Voltage Dimensions Weight
951000001 CV: MIG/ 120 V 30–125 110 A at 19.5 V, 60% duty cycle 23.0 — 2.8 2.8 60–600 ipm 58 VDC H: 12.5 in. 38 lb.
With running gear/cylinder rack flux-cored (1.5–15.2 m/min.) (318 mm) (17.2 kg)
240 V 30–230 200 A at 24 V, 20% duty cycle — 25.8 6.2 6.2
951674 W: 11.25 in.
150 A at 21.5 V, 40% duty cycle — 16.7 4.0 4.0
With TIG Contractor kit — (286 mm)
see page 128 for kit contents CC: TIG 120 V 20–150 140 A at 15.6 V, 40% duty cycle 24.6 — 3.0 3.0 — 58 VDC D: 20.5 in.
(521 mm)
240 V 20–210 190 A at 17.6 V, 20% duty cycle — 18.0 6.7 6.7
CC: Stick 120 V 30–100 90 A at 23.6 V, 40% duty cycle 22.7 — 2.7 2.7
240 V 30–200 190 A at 27.6 V, 20% duty cycle — 27.0 6.5 6.5
41
