MULTIPROCESS

® Industrial
Maxstar 280 Multiprocess See literature DC/35.5 Maxstar is DC only
®
Dynasty 300 Multiprocess See literature AD/4.97 Processes
1
AC /DC TIG (GTAW) Pulsed TIG (GTAW-P)
2
MIG (GMAW) Flux-cored (FCAW) 2
Multiprocess performance in a portable package. Designed for industrial
Stick (SMAW) Air carbon arc (CAC-A)
applications that require a versatile solution with superior arc performance. 1 Dynasty model only.
2 With ArcReach SuitCase wire feeder.
Comes with
8 ft. (2.4 m) power cord (no plug)
Two 50 mm Dinse-style connectors
See page 129
Two Dinse/Tweco® adapters
8 ft. (2.4 m) weld cable with Tweco®-
ArcReach ® SuitCase ® feeder style connectors to power feeder
paired with the CV output TIGRunner® includes above plus
of the Maxstar or Dynasty Small Runner Cart
™
™
power source gives this unit Coolmate 1.3
MIG process capabilities. Contractor package includes
Note: Maxstar and Dynasty are not above (except TIGRunner) plus
capable of ArcReach control. Contractor kit with A-200 TIG torch
and RFCS-14 HD foot control
(301549)
Maxstar 280 Multiprocess (far left) and Dynasty 300 ArcReach® SuitCase® 12 with two
Multiprocess (center) shown with ArcReach SuitCase 12 .035/.045 in. reversible V-groove
(packages available for Dynasty with ArcReach SuitCase, see below). drive rolls
Bernard® BTB Gun 300 A with
Allows for any input AccuLock consumables
™
voltage hook-up Complete package includes
(Maxstar: 208–575 V, Dynasty: 208–600 V) with no TIGRunner above plus
manual linking, providing convenience in any job setting. ArcReach® SuitCase® 12 with two
Ideal solution for dirty or unreliable power. .035/.045 in. reversible V-groove
drive rolls
Blue Lightning high-frequency (HF) arc starter for non-contact arc
™
Bernard® BTB Gun 300 A with
initiation. Provides more consistent arc starts and greater reliability
™
AccuLock consumables
compared to traditional HF arc starters. Coolant (4 one-gallon bottles)
Pulsed TIG can be used to increase puddle agitation, arc stability Wireless foot control
Weldcraft W-280 water-cooled
™
and travel speeds while reducing heat input and distortion.
torch kit
QuietPulse is activated by changing Most popular accessories
the waveshape for DC pulse welding ArcReach® SuitCase® Feeders (pg 16)
™
to create a slower, more fluid transition between the background Small Runner Cart 301615 (pg 123)
™
and peak amperage, resulting in lower audible noise. Coolmate 1.3 301616 (pg 123)
Contractor Kits (pg 128)
Machines manufactured after serial number ND040985L include QuietPulse. Those
manufactured before can be updated with QuietPulse ™ Expansion Memory Card (301790). 301311 w/RCCS-14 finger control
301309 w/RFCS-14 HD foot control
™
Fan-On-Demand cooling system only operates when needed,
Weldcraft ™ Water-Cooled Torch Kits
reducing power consumption and keeping internal components cleaner. (pg 128)
™
Cooler-On-Demand feature operates the auxiliary cooling system 300185 W-250 (WP-20)
300990 W-280 (WP-280)
only when needed. Reduces noise, energy use, and airborne
301268 W-375
contaminants pulled through the cooler. Dynasty 300 Multiprocess Complete package shown. Remote Controls (pg 128–129)
Visit MillerWelds.com or your distributor
*Refer to owner’s manual for complete ratings.
for other Miller®options and accessories.
**Sense voltage for low OCV stick and Lift-Arc ™ TIG.
Welding Input Welding Rated Output at Amps Input at Rated Load Output, 50/60 Hz Max. Open- Power Source Power Source
Model/Stock Number Process Power Amp Range 60% Duty Cycle 208 V 230 V 240 V 400 V 460 V 575 V 600 V KVA KW Circuit Voltage Dimensions Net Weight
Maxstar 280 Multiprocess TIG 3-phase 1–280 250 A at 20 V 21 19 — 11 9 7 — 7.6 7.3 60 VDC H: 13.6 in. 47 lb.
907552001 Power source only
(11 VDC**)
(21.3 kg)
(346 mm)
DC Maxstar See page 60 in the TIG section for Stick 3-phase 5–280 250 A at 30 V * * — 14 13 10 — 9.9 9.6 W: 8.6 in.
1-phase
35 32 — 18 16 13 — 7.3 7.1
250 A at 20 V
1–280
(219 mm)
Maxstar 280 Series
D: 22.5 in.
180 A at 27.2 V
5–280
1-phase
32 29 — * * * — 6.7 6.5
MIG/
flux-cored 3-phase 5–280 250 A at 26.5 V * * — 13 11 9 — 9.2 8.9 (569 mm)
1-phase 5–280 200 A at 24 V 31 29 — * * * — 6.5 6.3
Dynasty 300 Multiprocess TIG 3-phase 2–300 (AC) 250 A at 20 V 19 — 16 10 8 — 7 7.5 6.6 60 VDC H: 13.88 in. 55 lb.
907819 Power source only 1-phase 1–300 (DC) 250 A at 20 V 33 — 29 17 15 — 11 6.7 6.7 (11 VDC**) (352 mm) (25 kg)
AC/DC Dynasty 951000099 Contractor w/foot Stick 3-phase 1–300 (DC) 250 A at 30 V * — * 14 12 — 9 9.8 9.1 (216 mm)
W: 8.5 in.
907819001 TIGRunner
2–300 (AC)
and SuitCase 12
D: 21.88 in.
5–300
951000100 Complete w/wireless
(555 mm)
foot and SuitCase 12
5–300
1-phase
200 A at 27.2 V
35 — 31 * * — * 9.3 9.2
See page 61 in the TIG section for
Dynasty 300 Series MIG/ 3-phase 5–300 250 A at 26.5 V * — * 12 11 — 9 8.9 8.1
flux-cored 1-phase 5–300 200 A at 24 V 31 — 27 * * — * 6.2 6.1
