MULTIPROCESS

® Industrial
Multimatic 235 See literature DC/14.0
Processes
MIG (GMAW) Flux-cored (FCAW)
DC stick (SMAW)
DC Lift-Arc ™ TIG (GTAW)
Pulsed TIG (GTAW-P)
Comes complete with
Welding Capability 15 ft. (4.5 m) 250-amp MDX -250
™
MIG gun with AccuLock ™ MDX ™
Max. 3/8 in. (9.5 mm) Max. 3/8 in. (9.5 mm)
consumables
10 ft. (3 m) cable with electrode holder
Mild Steel Aluminum 10 ft. (3 m) work cable with clamp
7 ft. (2.1 m) industrial power cord
Min. 24 ga. (0.6 mm) Min. 18 ga. (1.2 mm)
Two factory-installed gas solenoids
Max. 3/8 in. (9.5 mm)
Flow gauge regulator and gas hose
See page 129 Max. 3/8 in. (9.5 mm)
for argon or AR/CO 2 mix
TIG Mild Steel Stick Mild Steel .030/.035 in. reversible V-groove
drive rolls
Min. 24 ga. (0.6 mm) Min. 16 ga. (1.5 mm)
Extra contact tips and material
Aluminum welding uses optional spool guns. thickness gauge (229895)
TIG welding uses optional Multimatic 235/255 TIG kit.
Most popular accessories
™
Spoolmate Spool Guns (pg 28)
300371 Spoolmate 100
301272 Spoolmate 150
300497 Spoolmate 200
Spoolmatic® Spool Gun (pg 29)
Multimatic 235 (non-Pro gun only)
with EZ-Latch single cylinder EZ-Latch Single Cylinder Running
™
running gear shown.
Gear 301449 (pg 122)
EZ-Latch ™ Dual Cylinder Rack with
Auto-Set Elite offers predefined weld settings to Elevated Gun and Cable Rack
™
increase ease of use and ensure that the job is done 301481 (pg 122)
right for operators of all skill levels. Converts an EZ-Latch ™ Single Cylinder
Running Gear into a Dual Cylinder
Available for MIG, stick and DC TIG processes with the
Rack Running Gear as seen below
ability to fine-tune your settings
Set weld parameters by:
MIG — selecting wire and gas type, wire diameter and
Easy-to-understand interface with 4.3-inch color material thickness
LCD display and intuitive connection setup images. Stick — selecting electrode type, electrode diameter
Weighing only 63 pounds (machine only), this and material thickness
™
lightweight MIG, stick and DC TIG welder provides DC Lift-Arc TIG — selecting remote on/off, tungsten
portability on the job. diameter and material thickness
™
Compatible with Spoolmate 100, 150 and 200, Pro-Set (TIG/stick) eliminates the guesswork when
™
and Spoolmatic 15A and 30A spool guns to offer a setting weld parameters. Use Pro-Set when you want the
variety of aluminum welding solutions. speed, convenience and confidence of preset controls.
EXCLUSIVE! Auto-Gun Detect automatically adjusts Two shielding gas connections (one for MIG gas and
™
voltage, wire speed and timers for faster switching one for TIG gas) so both gases can be left connected EZ-Latch ™ Dual Cylinder Running
between MIG and spool guns. to the machine — no switching needed. Gear 951769 (pg 122)
Protective Cover 301521 (pg 125)
Heavy-duty aluminum two-drive-roll system. Manual mode offers additional stick and TIG Multimatic 235/255 TIG Kit 301518
adjustments for increased control including adjustable (pg 128)
Uses 4-, 8- or 12-inch (102, 203 or 305 mm) spools.
DIG control for stick and 0.1–150 pulses per second for 10-Pin to 14-Pin Adapter Cord
DC pulsed TIG. 301545 (pg 128)
Wireless Remote Foot Control
™
Fan-On-Demand cooling system only operates when 301580 (pg 129)
needed, reducing power consumption and keeping Visit MillerWelds.com or your distributor
internal components cleaner. for other Miller®options and accessories.
*Input voltage range for the Multimatic 235 is 204–276 V.
**See literature DC/14.0 for dimensions and weight with running gear.
Stock Number Welding Amperage Amps Input at Rated Output, 50/60 Hz Max. Open- Power Source Power Source
907780 Mode/Process Range Rated Output 240 V* KVA KW Wire Feed Speed Circuit Voltage Dimensions** Net Weight**
951846 With EZ-Latch CV: MIG/flux-cored 30–235 170 A at 22.5 V, 20.0 5.0 4.9 60–600 ipm 54 VDC H: 19.25 in. (489 mm) 63 lb. (29 kg)
single cylinder running gear 60% duty cycle (1.5–15.2 m/min.) W: 13.75 in. (349 mm)
951847 With EZ-Latch CC: Stick 30–200 150 A at 26 V, 20.2 5.0 4.8 — D: 24.25 in. (616 mm)
dual cylinder rack running 60% duty cycle
gear and TIG kit
CC: DC TIG 20–210 180 A at 17.2 V, 17.0 4.2 4.1
60% duty cycle
43
