MULTIPROCESS

Heavy industrial
®
XMT 450 CC/CV ArcReach ® See literature DC/18.94 XMT 450
is 3-phase only.
Processes
™
Auto-Bind automatically establishes exclusive communication between the MIG (GMAW) Stick (SMAW)
power source and the wire feeder, using the existing weld cables upon system TIG (GTAW) Flux-cored (FCAW)
power up. RMD* Pulsed MIG (GMAW-P)*
Air carbon arc cutting and gouging
Operator can precisely set arc voltage at the feeder and monitor the actual
(CAC-A) (carbons — 304: 1/4 in.,
arc voltage and current delivered to the weld using the digital meters on the
350: 1/4 in., 450: 5/16 in.)
feeder. This removes guesswork when it comes to adhering to weld procedures.
*XMT 350 FieldPro only with ArcReach
Inadvertent parameter changes by other jobsite workers can be easily Smart Feeder.
avoided because connecting an ArcReach accessory from the power source Stick/TIG system includes
automatically locks out the power source’s panel controls. XMT 350 FieldPro power source
ArcReach Stick/TIG Remote
Return to a previous weld process faster because the power source is restored
Note: XMT 450 CC/CV ArcReach does not to its previous settings once the ArcReach accessory is removed. MIG/flux-cored system includes
support the Cable Length Compensation XMT 350 FieldPro power source
(CLC ™ ) and Adjust While Welding (AWW ™ ) Auto-Process Select decreases the chance of an incorrect weld process ArcReach SuitCase 12 feeder with
™
features or the ArcReach Smart Feeder. drive rolls
being used because it automatically sets the power source to the correct weld
Bernard® BTB Gun 300 A with
process based on the polarity applied to the weld accessory.
AccuLock ™ consumables
RMD/pulse system includes
XMT 350 FieldPro power source
ArcReach Smart Feeder with
® drive rolls
XMT 350 and 450 Racks See literature DC/18.81 Bernard® PipeWorx 300-15 MIG gun
Most popular accessories
All the benefits of an individual XMT in an easy-to-transport package for multiple arcs in the field. XR-AlumaFeed® SuitCase®
301567** (pg 9)
Flexible solution. The flexibility of the XMT makes it ideal for multiple system ArcReach ® SuitCase® Feeders
racks. Every system in a rack can be used for different tasks on-site, increasing (pg 16/51)
ArcReach® Smart Feeder (pg 16/51)
fleet utilization and making the best use of equipment budgets.
(for XMT 350 FieldPro power sources
Easy installation. The power distribution system on the rack allows the entire only)
rack to be wired into a single power drop, isolating high-voltage power in the field. ArcReach®
Heater
(pg 51/94)
Model Stock Number Input Power to Rack
(for XMT 350
XMT 350 FieldPro 907739 4-Pack Rack 230–575 V, three-phase FieldPro power
907740 6-Pack Rack (fused for 460/575 V)
sources only)
XMT 350 FieldPro 907742 4-Pack Rack 230–575 V, three-phase 20 Series and 74 MPa Plus
with Polarity Reversing 907741 6-Pack Rack (fused for 460/575 V)
Feeders** (pg 18)
XMT 450 CC/CV ArcReach 907700 4-Pack Rack 230/460 V, three-phase Spoolmatic®/WC-24** (pg 29/130)
(fused for 460 V)
ArcReach® Stick/TIG Remote
XMT 350 FieldPro Rack shown. Note: Also see page 50 for XMT 650 ArcReach Racks. 301325 (pg 51)
ArcReach® Stick/TIG Remote with
Polarity Reversing 300934 (pg 51)
(for XMT 350 FieldPro with Polarity
Reversing power source only)
**Not compatible w/polarity reversing model.
Visit MillerWelds.com or your distributor
*Optional 115-volt auxiliary power provides 10 amps of circuit-breaker protected power for coolant systems, etc.
for other Miller®options and accessories.
**Duty cycle rating below achieved with 6-gauge input power cord (8-gauge cord supplied with unit).
Amperage/ Max.Open- Power
Model/Stock Number Input Voltage Amps Input at Rated Load Output, 60 Hz Circuit Power Source Source
Most Popular Models Power Ranges Rated Output 208 V 230 V 400 V 460 V 575 V KVA KW Voltage Dimensions Net Weight
XMT 350 FieldPro System (Tweco®) 3-phase 5–425 A 350 A at 34 VDC, 40.4 36.1 20.6 17.8 14.1 14.2 13.6 75 VDC H: 17 in. (432 mm) 93 lb.
951736 Stick/TIG 10–38 V 60% duty cycle W: 12.5 in. (318 mm) (42.2 kg)
951734001 MIG/flux-cored D: 24 in. (610 mm)
951738 RMD/pulse
1-phase 5–425 A 300 A at 32 VDC, 60.8 54.6 29.7 24.5 19.9 11.7 11.2
XMT 350 FieldPro Power Source only
10–38 V 60% duty cycle**
907730 208–575 V with Tweco®
350 A 907730002 208–575 V with Dinse 3-phase 5–425 A 350 A at 34 VDC, 40.4 36.1 20.6 17.8 14.1 14.2 13.6 75 VDC H: 17 in. (432 mm) 93 lb.
XMT 350 FieldPro w/Polarity Reversing System (Tweco®)
951737 Stick/TIG 10–38 V 60% duty cycle W: 12.5 in. (318 mm) (42.2 kg)
951735001 MIG/flux-cored D: 24 in. (610 mm)
951739 RMD/pulse
1-phase 5–425 A 300 A at 32 VDC, 60.8 54.6 29.7 24.5 19.9 11.7 11.2
XMT 350 FieldPro w/Polarity Reversing Power Source only 10–38 V 60% duty cycle**
907731 208–575 V with Tweco®
907731001 208–575 V with Dinse
XMT 450 CC/CV ArcReach (1/2 in. stud) 3-phase 15–600 A 450 A at 38 VDC, — 51 — 27.6 24.4 22 18.9 90 VDC H: 17.25 in. (438 mm) 122 lb.
450 A 907481003 230/460 V 10–38 V 100% duty cycle W: 14.5 in. (368 mm) (55.3 kg)
D: 27.125 in. (689 mm)
907481004 230/460 V w/auxiliary power*
907482 575 V
49
