STICK SMAW
® Industrial
Maxstar 210 STR See literature DC/32.1
Processes
Maximum flexibility with automatic connection to any input power while maintaining the best Stick (SMAW) TIG (GTAW)
DC stick/TIG welding performance in its product class. Comes complete with
8 ft. (2.4 m) power cord (no plug)
Two 50 mm Dinse-style connectors
Allows for any input voltage hookup
(120–480 V) with no manual linking, Most popular accessories
™
12.5 ft. (3.8 m) Weldcraft A-150
providing convenience in any job setting. Ideal solution for dirty or
Valve TIG torch WP-17V-25-2 (pg 66)
unreliable power.
Remote Controls (pg 128)
Lift-Arc provides DC TIG arc initiation without the use of high frequency. Air-Cooled TIG Torch Connector
™
(pg 129)
Dual schedule allows operators to switch between welding parameters
Visit MillerWelds.com or your distributor
for specific electrodes without readjusting the machine. for other Miller®options and accessories.
™
Hot Start adaptive control provides positive arc starts without sticking.
Stick-Stuck detects if the electrode is stuck to the part and turns
the welding output off to safely and easily remove the electrode.
Menu selectable.
™
Fan-On-Demand power source cooling system operates only when
needed, reducing noise, energy use and the amount of contaminants
pulled through the machine.
Remote amperage control.
Digital meters for more precise control when presetting or monitoring
welding amperage.
Portable with adjustable shoulder strap.
*Sense voltage for stick and Lift-Arc TIG.
Stock Number Welding Welding Rated Output at Amps Input at Rated Load Output, 50/60 Hz Max. Open- Net
907682 Process Input Power Amperage Range 60% Duty Cycle 120 V 208 V 240 V 400 V 480 V KVA KW Circuit Voltage Dimensions Weight
See page 60 in Stick 3-phase 10–210 160 A at 26.4 V — 15 13 8 6 5.5 5.2 80 VDC H: 13.6 in. 36 lb.
the TIG section for 1-phase 10–210 160 A at 26.4 V — 26 22 13 11 5.3 5.3 (11 VDC*) (346 mm) (16.3 kg)
Maxstar 210 Series W: 8.6 in.
1-phase (120 V) 10–100 90 A at 23.6 V 23 — — — — 2.8 2.8 (219 mm)
TIG 3-phase 10–210 210 A at 18.4 V — 14 12 7 6 5.2 4.9 D: 19.5 in.
(495 mm)
1-phase 10–210 210 A at 18.4 V — 24 20 12 10 4.9 4.9
1-phase (120 V) 10–150 125 A at 15 V 22 — — — — 2.6 2.6
