MIG GMAW POWER SOURCES/PACKAGES

Heavy industrial
™
Continuum Systems See literature DC/36.0
Processes
Next generation of advanced industrial welding solutions improves productivity through Accu-Pulse® MIG (GMAW-P)
Versa-Pulse ™ RMD ® MIG (GMAW)
weld quality, ease of use and system flexibility. High-deposition MIG (GMAW)
Flux-cored (FCAW)
Power source design Air carbon arc gouging (CAC-A)
Smart and powerful digital design has the fast MIGRunner ™ packages include
response needed to deliver the most stable welding Continuum power source
Push-only pkg: Continuum single-wire
performance for better welding results.
feeder with .035/.045 in. V-groove
Continuum 350 Flexible to meet current and future needs with drive rolls and Bernard® BTB Gun
push-only MIGRunner 400 A with AccuLock ™ consumables
package shown (motor integrated expansion capabilities.
cable not pictured). Push-pull pkg: Continuum dual-wire
Welding Intelligence. Get more done, produce feeder with .035/.047 in. U-groove
™
higher-quality welds and control costs. and .035/.045 in. V-groove drive
Insight Core (standard) gives owners/managers rolls, XR-Aluma-Pro Plus gun,
™
and Bernard® BTB Gun 400 A with
visibility of welder productivity, to make informed
AccuLock ™ consumables
decisions to drive improvements (see page 74).
Continuum running gear/cylinder rack
™
Insight Centerpoint (optional) gives real-time and handles/cable hangers
guidance to welders, so less training is required and 3 ft. (0.9 m) control/motor cable
weld quality is improved (see page 75). Industrial MIG 4/0 kit consisting of
flowmeter regulator(s) with 10 ft.
Feeder design (3 m) gas hose(s), 10 ft. (3 m)
4/0 feeder weld cable with lugs,
Accu L ck TM Continuum wire feeders and 15 ft. (4.6 m) work cable with
include a Bernard® BTB Gun
600-amp C-clamp
400 A (two with dual-wire feeders) with AccuLock ™ Wire feeding options
consumables. Continuum Feeders* (see chart below)
Continuum Swingarc ™ Feeders*
™
Tru-Feed technology provides precise feeding
951635001 12 ft. (3.7 m) single-wire
operation for stable arc performance. 951636001 16 ft. (4.9 m) single-wire
More power — better reliability Low-inertia motor provides faster response for the 951725001 12 ft. (3.7 m) dual-wire
Up to 26 percent more welding output (than competitive best arc starts with the least amount of spatter. *Feeders include .035/.045 in. V-groove
models) for demanding industrial applications. Balanced-pressure drive-roll design and tensioners drive rolls and a Bernard BTB Gun 400 A
(two with dual-wire models) with AccuLock
Allows for any input voltage feed wire in its truest and straightest form for consistent consumables.
hookup (230–575 V, three- feedability, resulting in better welding performance. See literature DC/36.0 for additional
booms and options
phase) with no manual linking, providing convenience in User-friendly interface makes the system easy to set
any job setting. Ideal solution for dirty or unreliable power. up and adjust with minimal training. Most popular accessories
Bernard® MIG Guns (pg 26–27)
Insight Centerpoint ™ Software (pg 75)
Continuum Processes
Continuum Running Gear/Cylinder
Ratings A, B, C, and D are relative values.
Standard High-Deposition An “A” rating indicates a best fit between Rack 301264 (pg 123)
Best For Spray MIG Accu-Pulse Versa-Pulse Short Circuit RMD your performance needs and process. Industrial MIG 4/0 Kits (with lug
connectors) (pg 125)
Deposition A A A B D D A “blank” rating indicates that the process
is not recommended for that application. Continuum Integrated Cooler 301214
Gap Filling D D B B A A
Accu-Pulse is the most popular process for Mounts to bottom of power source —
Low Heat Input D C B A A A
majority of industrial welding applications. does not require external power
Out-of-Position Welds A B B B Versa-Pulse is a fast, low-heat, low-spatter Motor/Control Cables
Low Spatter A A A B C B process designed for thin-material applications. 263368003 3 ft. (0.9 m)
Thick Metals A A A C D D RMD is a low-heat, modified short-circuit 263368015 15 ft. (4.6 m)
process designed to fill gaps with 263368025 25 ft. (7.6 m)
Thin Metals B A A A
thin-material applications. 263368050 50 ft. (15 m)
Increased Travel Speed A A A A B C High-deposition MIG provides increased 263368080 80 ft. (24.4 m)
HOT COLD deposition rates over standard spray on 263368100 100 ft. (30.5 m)
thicker materials.
Visit MillerWelds.com or your distributor
*While idling. for other Miller®options and accessories.
Amp/Volt Amps Input at Rated Output, 50/60 Hz, 3-Phase Max. Open- Power Source Dimensions Power Source
Model Stock Number Ranges Rated Output 230 V 380 V 400 V 460 V 575 V KVA KW Circuit Voltage (Includes lift eye) Net Weight
Continuum 951852001 Push-only MIGRunner package 20–400 A 350 A at 36.7 21.8 20.8 18.8 14.6 14.4 13.8 71 VDC H: 27.187 in. (691 mm) 127 lb.
350 951865001 Push-pull MIGRunner package 10–44 V 31.5 VDC, 0–1* 0–1* 0–1* 0–1* 0–1* 0.8* 0.17* W: 17.5 in. (444 mm) (57.6 kg)
907636 Power source only 100% duty cycle D: 28.125 in. (714 mm)
907636001 With running gear/cylinder rack
Continuum 951853001 Push-only MIGRunner package 20–600 A 500 A at 57.6 34.7 33.2 28.9 23.3 23.1 21.9 71 VDC 148 lb.
500 951866001 Push-pull MIGRunner package 10–44 V 39 VDC, 0–1* 0–1* 0–1* 0–1* 0–1* 0.8* 0.17* (67.1 kg)
907640 Power source only 100% duty cycle
907640001 With running gear/cylinder rack
Input Input Welding Maximum Spool
Model/Stock Number Power Circuit Rating Wire Feed Speed Wire Diameter Capacity Size Capacity Dimensions Net Weight
Continuum Feeder 50 VDC 500 A at Standard: .035–5/64 in. 18 in. (457 mm), H: 13.812 in. (351 mm) Single: 43 lb. (19.5 kg)
951631001 Single-wire model 100% duty cycle 50–1,000 ipm (0.9–2.0 mm) 60 lb. (27 kg) Single W: 16.312 in. (414 mm) Dual: 61.5 lb. (27.9 kg)
951673001 Dual-wire model (1.3–25.4 m/min.) Dual W: 17 in. (432 mm)
D: 29.687 in. (754 mm)
12
