GTAW TIG

®
Syncrowave 300 and 400 AC/DC TIG and Stick Industrial
Processes
See literature AD/4.25 (300) and AD/4.28 (400) TIG (GTAW) Stick (SMAW)
DC pulsed TIG (GTAW-P)
Comes with
10 ft. (3 m) power cord (no plug)
TIG Welding Capability Two 50 mm Dinse-style connectors
400 Max. TIGRunner® includes above plus
5/8 in. (15.9 mm) 400 Max. Syncrowave 300/400 4-Wheel Cart
1/2 in. (12.7 mm) Coolmate ™ 3S
300 Max. Complete packages include
1/2 in. (12.7 mm) 300 Max.
3/8 in. (9.5 mm) above plus
Steel Aluminum Coolant (four 1-gallon bottles)
Remote control (foot or wireless foot)
Min. 0.012 in. (0.3 mm) Min. 0.015 in. (0.4 mm)
Weldcraft ™ water-cooled torch kit
Syncrowave 300: W-280
Syncrowave 400: W-375
Most popular accessories

See page 129

Syncrowave 300
machine only
Syncrowave 300/400 4-Wheel Cart
301601 (pg 123)
Syncrowave 400 Complete package
with foot control Coolant 043810 (pg 123)

Auto-Link circuit automatically links the power source Auto-postflow adjusts the length of postflow time based
®
to primary voltage being applied (208/240/480 V, on the amperage setting, shielding your tungsten and
single- or three-phase). eliminating the need to set the postflow time.
AC frequency controls the width of the arc cone and Pro-Set eliminates the guesswork when setting weld
™
can improve directional control of the arc (50–150 Hz). parameters. Use Pro-Set when you want the speed, Weldcraft ™ Water-Cooled Torch Kits
convenience and confidence of preset controls. (pg 128)
AC balance control features adjustable cleaning action
300990 W-280 (WP-280)
while increasing arc stability on various aluminum alloys, Arc timer/cycle counter records actual welding time
301268 W-375
and helps eliminate tungsten spitting and arc rectification. and number of arc starts. Great for estimating job costs.
Remote Controls (pg 128–129)
Blue Lightning high-frequency (HF) arc starter for Line voltage compensation keeps power source 043688 RCCS-14 fingertip control
™
non-contact arc initiation. Provides more consistent constant regardless of fluctuations in input power 301589 RFCS-14 HD foot control
301580 Wireless foot control
arc starts and greater reliability compared to traditional (±10 percent).
Visit MillerWelds.com or your distributor
HF arc starters.
Coolmate 3S cooler (shown in Complete package). for other Miller®options and accessories.
™
Lift-Arc provides AC or DC arc initiation without the use Three-gallon cooling system features a flow indicator
™
of high frequency. to visually indicate system is working and an external
filter to stop objects from entering the water-cooled
torch cable.
1 For Syncrowave 400 refer to owner’s manual for 208 V output rating and duty cycle.
2 Sense voltage for low OCV stick and Lift-Arc ™ TIG.
3 See literature AD/4.25 and AD/4.28 for Complete package dimensions and weight.
Input Welding Rated Output at Amps Input at Rated Output, 50/60 Hz Max. Open- Power Source Power Source
Model/Stock Number Welding Process Power Amp Range 60% Duty Cycle 1 208 V 240 V 480 V KVA KW Circuit Voltage Dimensions 3 Net Weight 3
Syncrowave 300 TIG (includes cooler 3-phase 5–300 210 A at 18.4 V 16 14 7 5.9 5.5 60 VDC H: 29.4 in. (746 mm) 101 lb.
907782 Power source only power draw) (13 VDC 2 ) W: 15 in. (381 mm) (45.8 kg)
1-phase 5–300 210 A at 18.4 V 27 24 12 5.7 5.5
907782001 TIGRunner® Stick 3-phase 5–230 160 A at 26.4 V 16 11 5 5.7 5.5 D: 24.6 in. (625 mm)
AC/DC 951000003 Complete w/foot 1-phase 5–230 160 A at 26.4 V 27 23 11 5.7 5.5
951872 Complete w/wireless foot
Syncrowave 400 TIG (includes cooler 3-phase 5–400 300 A at 22 V 25 23 11 9.1 8.8 70 VDC H: 29.4 in. (746 mm) 131 lb.
907783 Power source only power draw) 1-phase 5–400 300 A at 22 V 43 42 20 9.7 8.9 (13 VDC ) 2 W: 15 in. (381 mm) (59.4 kg)
907783001 TIGRunner® D: 24.6 in. (625 mm)
951000004 Complete w/foot Stick 3-phase 5–300 250 A at 30 V 27 24 12 9.8 9.4
951873 Complete w/wireless foot 1-phase 5–300 250 A at 30 V 47 43 21 10.4 9.5
