TIG GTAW

Syncrowave 210 Light industrial
®
Processes
AC/DC TIG (GTAW) DC stick (SMAW)
AC/DC TIG, Stick and MIG (with Spool Gun) See literature AD/4.6
Pulsed TIG (GTAW-P) MIG (GMAW)*
Continuing the tradition of innovation through advanced inverter technology Flux-cored (FCAW)*
*With Spoolmate 150.
for light-industrial users.
Comes with
10 ft. power cord with MVP plugs for
120 V and 240 V
12.5 ft. (3.8 m) Weldcraft ™ A-150 TIG
torch (WP1712MFDI50)
12 ft. (3.7 m) work cable with clamp
and Dinse-style connector
Electrode holder with Dinse-style
Syncrowave 210 connector
TIG/stick only
package shown. RFCS-14 HD foot control
Flow gauge regulator with hose
See page 129 Factory-installed running gear with
Easy to use.
EZ-Change ™ low cylinder rack
1) Turn power on. Quick-reference guide
2) Select the process.
TIG/MIG Complete package
3) Set amperage or voltage includes above plus
based on material thickness. Spoolmate 150 spool gun (301272)
™
Then weld! It’s easy as 1,2,3. 4-14 pin connector
Flow-thru Dinse-style connector
Most popular accessories
25 ft. (7.6 m) Weldcraft ™ A-150
TIG Welding Capability
TIG Torch WP-17-25-R (pg 66)
Max. 1/4 in. (6.4 mm)
Steel Aluminum
Min. 0.020 in. (0.5 mm)

TIG Torch Accessory Kit AK2C (pg 72)
Includes one short back cap, one
of each size (#4, #5, #6) alumina
nozzle, and one of each size (.040,
Allows for any input voltage AC frequency (TIG) controls the width of the arc cone 1/16, 3/32 in.) of the following:
hookup (120–240 V) with and can improve directional control of the arc. collet, collet body, and 7-inch
no manual linking, providing convenience in any job AC balance (TIG) control provides adjustable oxide 2% ceriated tungsten electrode
setting. Ideal solution for dirty or unreliable power. TIG Torch Accessory Kit AK-150MFC
removal which is essential for creating the highest (pg 72)
™
Multi-voltage plug (MVP ) quality aluminum welds. Converts A-150 into 28 different
allows for connection to torch styles while using existing
Pulse (TIG). Pulsing can increase puddle agitation,
120- or 240-volt receptacles cable — includes collets, collet
arc stability and travel speeds while reducing heat input bodies, nozzles, torch heads,
without tools. Choose the plug
and distortion. handle and more
that fits the receptacle and Protective Cover 195142 (pg 128)
connect it to the power cord. DIG (stick) control allows the arc character istics to RCC-14 Remote Control 151086
be changed for specific applications and electrodes.
Low power draw. Inverter-based power source provides (pg 128)
Lower the DIG setting for smooth running electrodes Wireless Remote Foot Control
full welding output from 240 volts while drawing less
like E7018 and increase the DIG setting for stiffer, 301580 (pg 129)
than 30 amps.
more penetrating electrodes like E6010. Visit MillerWelds.com or your distributor
High-frequency (HF) arc starting for non-contact arc Auto-Set (MIG) automatically sets your welder to the for other Miller®options and accessories.
™
initiation, reducing tungsten and material contamination.
proper parameters. Simply set the wire size, material
™
Pro-Set (TIG/stick) eliminates the guesswork when thickness, and shielding gas and you’re ready to weld
™
setting weld parameters. Use Pro-Set when you want the with the Spoolmate spool gun.
speed, convenience and confidence of preset controls.
Stock Number Input Welding Welding Rated Output (R.M.S.) Amps Input at Max. Open-
907596 Power Process Amperage Range at 60% Duty Cycle Rated Output Circuit Voltage Dimensions Net Weight
TIG/stick only package 115 V DC TIG 5–125 95 A at 13.8 V 17.4 (.58 while idling) 47 VDC H: 31.5 in. (800 mm) TIG/stick only:
133.5 lb. (61 kg)
W: 18.5 in. (470 mm)
951684
AC/DC TIG/MIG Complete package — AC TIG 5–125 90 A at 13.6 V 12.4 (.58 while idling) D: 43 in. (1092 mm) TIG/MIG Complete:
20–90
20.5 (.58 while idling)
70 A at 22.8 V
DC stick
includes Spoolmate 150
230 V DC TIG 5–210 125 A at 15 V 11.9 (.35 while idling) 139.5 lb. (63 kg)
AC TIG 5–210 114 A at 14.6 V 8.62 (.35 while idling)
DC stick 20–150 90 A at 23.6 V 11.9 (.35 while idling)
58
