GTAW TIG

®
Dynasty 210/300 Series AC/DC TIG and Stick Industrial
Processes
See literature AD/4.81 (210) and AD/4.96 (300) TIG (GTAW) Stick (SMAW)
Pulsed TIG (GTAW-P)
TIG Welding Capability Air carbon arc (CAC-A) with 300 model
210 Max. 210 Max. Comes with
1/4 in. (6.4 mm) 1/4 in. (6.4 mm) 8 ft. (2.4 m) power cord (no plug)
Two 50 mm Dinse-style connectors
Steel Aluminum
TIGRunner® includes above plus
210 Min. 210 Min.
™
Small Runner Cart
0.002 in. (0.05 mm) 0.012 in. (0.3 mm)
Coolmate 1.3
™
300 Max. 300 Max.
3/8 in. (9.5 mm) 3/8 in. (9.5 mm) Complete packages include
See page 129 above plus
Coolant (four 1-gallon bottles)
Steel Aluminum Wireless foot remote control
300 Min. 300 Min. Weldcraft ™ water-cooled torch kit
0.004 in. (0.1 mm) 0.012 in. (0.3 mm) Dynasty 210: W-250
Dynasty 300
Dynasty 210
Dynasty 300: W-280
Most popular accessories
Intuitive LCD display. Ensures proper machine setup QuietPulse is activated by 2-Wheel TrolleyCart 300971
and parameter selection. Informative on-screen changing the waveshape (pg 123)
explanations and dynamic images enhance the for DC pulse welding to create a slower, more fluid Small Runner ™ Cart 301615
(pg 123)
parameter selection process. transition between the background and peak amperage,
Coolmate ™ 1.3 301616 (pg 123)
Program memory allows easy naming, saving and resulting in lower audible noise. Coolant 043810 (pg 123)
recalling of favorite weld settings. Pro-Set eliminates the guesswork when setting weld
™
Locks and limits provide control of weld parameter parameters. Use Pro-Set when you want the speed,
ranges, minimizing deviation from the welding convenience and confidence of preset controls. Simply
procedure specification (WPS). select the feature and adjust until Pro-Set appears on
the display.
USB. Front panel port provides the ability to easily
update software, back-up settings and transfer saved AC waveforms (TIG) for advanced squarewave, soft Contractor Kits (pg 128)
301309 A-150 w/RFCS-14 HD
weld programs from one unit to the next. squarewave, sine wave and triangular wave. 301311 A-150 w/RCCS-14
Allows for any input voltage AC balance (TIG) control provides adjustable oxide 301549 A-200 w/RFCS-14 HD
hookup (210 models: removal which is essential for creating the highest 301550 A-200 w/RCCS-14
120–480 V, 300 models: 208–600 V) with no manual quality aluminum welds.
linking, providing convenience in any job setting. Ideal AC frequency (TIG) controls the width of the arc cone
solution for dirty or unreliable power. and can improve directional control of the arc.
™
Blue Lightning high-frequency (HF) arc starter for Optional cooler power supply (CPS) is an integrated
non-contact arc initiation. Provides more consistent 120-volt dedicated-use receptacle for the Coolmate 1.3. Weldcraft ™ Water-Cooled Torch Kits
™
arc starts and greater reliability compared to traditional Cooler-On-Demand (CPS models only) feature operates (pg 128)
™
HF arc starters. 300185 W-250 (WP-20)
the auxiliary cooling system only when needed. Reduces
Lift-Arc provides AC or DC arc initiation without the noise, energy use, and airborne contaminants pulled 300990 W-280 (WP-280)
™
use of high frequency. through the cooler. 301268 W-375
Remote Controls (pg 128–129)
Auto-postflow adjusts the length of postflow time 043688 RCCS-14 fingertip control
based on the amperage setting, shielding your tungsten 301589 RFCS-14 HD foot control
and eliminating the need to set the postflow time. 301580 Wireless foot control
Visit MillerWelds.com or your distributor
for other Miller®options and accessories.
*Additional packages are available — visit MillerWelds.com or your distributor.
**Refer to owner’s manual for complete ratings. ***Sense voltage for low OCV stick and Lift-Arc ™ TIG.
Welding Welding Rated Output at Amps Input at Rated Load Output, 50/60 Hz Max. Open- Net
Model/Stock Number* Process Input Power Amp Range 60% Duty Cycle 120 V 208 V 240 V 400 V 460 V 480 V 600 V KVA KW Circuit Voltage Dimensions Weight
Dynasty 210 TIG 3-phase 1–210 210 A at 18.4 V — 16 14 8 — 7 — 5.7 5.2 80 VDC H: 13.88 in. 47 lb.
907816 Power source only 1-phase 1–210 210 A at 18.4 V — 28 23 14 — 12 — 5.8 5.6 (11 VDC***) (352 mm) (21.3 kg)
907816001 Power source w/CPS 1-phase (120 V) 1–150 125 A at 15 V 26 — — — — — — 2.8 2.7 W: 8.5 in. 50 lb.
907816002 TIGRunner w/CPS (216 mm) (22.7 kg)
Stick 3-phase 5–210 160 A at 26.4 V — 16 14 9 — 8 — 6.0 5.8 D: 21.88 in. with CPS
951936 Complete with
AC/DC wireless foot and CPS 1-phase 5–210 160 A at 26.4 V — 28 24 14 — 12 — 6.4 5.5
(555 mm)
90 A at 23.6 V
5–100
1-phase (120 V)
27 — — — — — — 2.9 2.8
Dynasty 300 TIG 3-phase 2–300 (AC) 250 A at 20 V — 19 16 10 8 — 7 7.5 6.6 60 VDC H: 13.88 in. 55 lb.
907818 Power source w/CPS 1–300 (DC) (11 VDC***) (352 mm) (25 kg)
W: 8.5 in. with CPS
907818002 TIGRunner w/CPS 1-phase 2–300 (AC) 250 A at 20 V — 33 29 17 15 — 11 6.7 6.7
(216 mm)
951937 Complete with 1–300 (DC) D: 21.88 in.
wireless foot and CPS Stick 3-phase 5–300 250 A at 30 V — ** ** 14 12 — 9 9.8 9.1 (555 mm)
See page 45 in the Multiprocess
1-phase 5–300 200 A at 27.2 V — 35 31 ** ** — ** 9.3 9.2
section for Dynasty 300 Multiprocess
